51

STMiE3E ed 09/11

MINI EOLO 3 E

Technical Documentation

Technical Documentation

ERROR 12

Storage tank probe anomaly

(in case of connection to an external storage tank, X versions )

The boiler prevents functioning in DHW mode but can function in CH mode.

12

The wiring between the storage tank probe and the board (connector

X2 terminals 6-7) is OK.

No

Restore the electric connection/replace the wiring.

 Yes

Replace the storage tank NTC probe. If the anomaly persists, replace the P.C.B.

ERROR 15

Configuration error

N.B.:  this  P.C.B.  can  be  used  for  instantaneous  sealed  chamber  /  open  chamber

boilers or with a storage tank. The board automatically recognises the type of boiler

by means of the relative wiring of the P.C.B.

15

The P.C.B. is configured for instantaneous sealed chamber boilers. No

For MINI EOLO type boilers, check the following connections.

- flue pressure switch wiring.

 Yes

Replace the P.C.B.

ERROR 20

Parasite flame block

20

The detection electrode and the relative wiring are integral.

No

Check/replace detection electrode/replace wiring.

 Yes

Replace the P.C.B.

ERROR 24

Push button control panel anomaly

24

The buttons on the control panel function regularly (check that a

"click" is heard when the button is pressed).

No

Check that there are no keys blocked or jammed under the control panel.

 Yes

Replace the P.C.B.

ERROR 27

Insufficient circulation

27

The boiler pump functions correctly.

N.B.: make sure that the pump functions at maximum speed.

No

See section B

 Yes

Any CH system zone valve or cut-off cocks are open.

No

Restore  circulation  in  the  CH  system  by  acting  on  the  closed  devices

and also check:

- the correct positioning/functioning of the boiler by-pass;

- the opening times of any zone valves (when necessary, it is possible to

delay ignition of the burner by acting on the boiler "P8" parameter);

- the correct functioning of any thermostatic valves.

 Yes

The NTC flow probe is OK (10 kΩ at 25°C).

No

Replace NTC probe.

 Yes

Check/clean/replace the main heat exchanger. If the anomaly persists, replace the P.C.B.
