43

STMiE3E ed 09/11

MINI EOLO 3 E

Technical Documentation

Technical Documentation

  MINI EOLO X 24 - Technical Data

Nominal heat input

kW (kcal/h)

25.6 (22051)

** DHW minimum heat input

kW (kcal/h)

8.3 (7117)

CH minimum heat input

kW (kcal/h)

10.5 (9057)

Nominal heat output (useful)

kW (kcal/h)

24.0 (20640)

** DHW minimum heat output (useful)

kW (kcal/h)

7.2 (6192)

CH minimum heat output (useful)

kW (kcal/h)

9.3 (7998)

Efficiency at nominal heat output

%

93.6

Efficiency at 30% nominal heat output load

%

90.3

Heat loss at case with burner On/Off

%

0.80 / 0.60

Heat loss at flue with burner On/Off

%

5.60 / 0.06

Central heating circuit max. operating pressure

bar

3

Central heating circuit max. operating temperature

°C

90

Adjustable central heating temperature

°C

35 - 85

System expansion vessel total volume

l

4

Heating expansion tank pre-charge

bar

1

Water content in generator

l

2.5

Total head available with 1000 l/h flow rate

kPa (m H

2

O)

24.52 (2.5)

** Hot water production useful heat output

kW (kcal/h)

24.0 (20640)

** Domestic hot water adjustable temperature

°C

10 - 60

** Min. pressure (dynamic) domestic hot water circuit

bar

0.3

** Domestic hot water circuit max. working pressure

bar

10

*Specific capacity “D” UB Immergas 80 l (∆T 30°C) according to EN 625

l/min

20.7

*Specific capacity “D” UB Immergas 105 l (∆T 30°C) according to EN 625

l/min

24.4

*Specific capacity “D” UB Immergas 120 l (∆T 30°C) according to EN 625

l/min

26.7

*Specific capacity “D” UB Immergas 200 l (∆T 30°C) according to EN 625

l/min

35.1

Drawing capacity in continuous duty with UB Immergas (∆T 30°C)

l/min

11.1

Weight of full boiler

kg

33.9

Weight of empty boiler

kg

31.4

Electrical connection

V/Hz

230/50

Power input

A

0.66

Installed electric power

W

130

Pump consumption

W

87.0

Fan consumption

W

35.0

Equipment electrical system protection

-

IPX5D

NO

X

 class

-

3

Weighted NO

X

mg/kWh

138

Weighted CO

mg/kWh

95

Type of appliance

C12 /C32 / C42 / C52 / C82 / B22 / B32

Category

II2H3+

-  Flue temperature values refer to an air inlet temperature of

15°C.

-  The data relevant to domestic hot water performance refers

to a dynamic inlet pressure of 2 bar and an inlet temperature

of 15°C; the values are measured directly at the boiler outlet

considering that to obtain the data declared mixing with cold

water is necessary.

-  The max. sound level emitted during boiler operation is <

55dBA.  The  sound  level  value  is  referred  to  semianechoic

chamber tests with boiler operating at max. heat output, with

extension of flue gas exhaust system according to product

standards.

-* Specific  flow  rate  “D”:  domestic  hot  water  flow  rate

corresponding  to  an  average  increase  of  30K,  which  the

boiler can supply in two successive withdrawals.

-** When the boiler is connected to an external storage tank.
