39
STMiE3E ed 09/11
MINI EOLO 3 E
Technical Documentation
Technical Documentation
Programming the P.C.B.
The boiler is prepared for possible programming of several
operation parameters. By modifying these parameters as
described below, the boiler can be adapted according to
specific needs.
To access the programming phase, press the “Reset” and 2
buttons (
) simultaneously for 8 seconds.
once the programming menu has been entered, the display will
alternate the number of the parameter with its current value.
Id
Parameter
Parameter
Description
Range
Default
P1
Boiler mode
(DO NOT MODIFY)
Defines the boiler's functioning mode:
0 - Instant boiler.
1 - Boiler with storage tank.
0 - 1
0
P2
Display lighting
Establishes the display lighting mode:
0 - Off: the display is always lit with low intensity.
1 - Auto: the display lights up when it is used and lights
off after 15 seconds of no activity.
2 - On: the display is always lit with high intensity.
0 - 2
2
P3
DHW thermostat
Establishes the switch-off method in DHW mode.
0 - Correlated: the boiler switches off on the basis of the
temperature set.
1 - Fixed: the switch-off temperature is fixed on the
maximum value independently from the value set on the
control panel.
In case of "X" version connected to a external storage tank
unit coupling kit (optional):
0 OFF 1: The boiler turns off at the Set-point, the boiler
turns off at the Set-point -3K.
1 OFF 2: The boiler turns off at the Set-point, the boiler
turns off at the Set-point -10K.
0 - 1
1
Using keys 3 and 4 ( -
) select the parameter to be
changed, with keys 5 and 6 ( - ) it is possible to change
the value of the selected parameter.
Confirm the changes by pressing the Reset button for about
3 seconds.
Exit the programming phase by waiting for the 15-minute
time-out to elapse or by pressing the "Reset" and 2 (
)
buttons together.
Information Menu
Pressing buttons 3 and 4 for 5 seconds ( -
), the
“Information menu” is activated, which allows to display some
of the boiler's functioning parameters.
Press buttons 3 and 4 ( - ) to scroll through the various
parameters.
To exit the menu, press buttons 3 and 4 ( - ) again for
5 seconds or press button 2 (
) for 5 seconds, or wait for
60 seconds.
Id Parameter
Description
d1
Displays the flame signal (uA)
d2
Displays the primary exchanger output instant heating flow temperature
d3
Displays the instant output temperature from the DHW exchanger
d4
Displays the temperature set for the central heating set (if remote control is present)
d5
Displays the temperature set for the DHW set (if remote control is present)
d6
Displays the external temperature (if external probe present)
If the temperature is below zero, the value is displayed flashing.
