36

STMiE3E ed 09/11

MINI EOLO 3 E

Technical Documentation

Technical Documentation

P.C.B. safety functions

If, once the fan has been powered, no air flow has been detected (flue pressure switch contact

is closed), after 20 seconds the anomaly will be displayed.

The fan stays on until the flue pressure switch contact has been closed, for the entire duration

of the request for heat.

If,  when  the  request  for  heat  is  on,  the  air  flow  is  restored  (flue  pressure  switch  contact

closed), the boiler will automatically start up the ignition cycle.

Fan anomaly

The  P.C.B.  carries  out  a  periodical  self-check  to  control  its  correct  functioning.  During

functioning  in  heating  mode  or  with  boiler  in  stand-by,  the  function  activates  every  18

hours after the last boiler check/power supply.

When operating in domestic hot water mode the self-check starts within 10 minutes after

the end of the flow in progress, for a duration of approx. 10 seconds.

N.B.:

during self-check, the boiler remains off, including signalling.

Periodical self-check

After 24 hours from the last activation, independently from the functioning status of the

boiler  (Summer  or Winter),  the  pump  (M1)  is  started  for  a  time  of  60  seconds  and  the

three-way valve (M30) is started for a period of 10 seconds.

Three-way valve/anti-

block pump

In the case of: anomaly on the gas valve pilot circuit; no electric connection to the gas valve

(interrupted gas valve coils); error inside the integrated P.C.B.

Generic boiler P.C.B.

anomaly

In  the  case  of  dispersion  of  the  detection  circuit  or  anomaly  in  the  flame  control  that

generates a correct ionisation current (without the gas valve being open) with the duration

of at least 20 seconds, boiler functioning is blocked.

To  re-start  the  appliance,  press  the  “Reset”  button  and  then  make  a  central  heating  or

domestic hot water request.

Parasite flame block

If the contact of the water overheating safety thermostat is opened (temperature of the primary

circuit exceeding 100 °C), boiler functioning is blocked.

To  re-start  the  appliance,  press  the  “Reset”  button  and  then  make  a  central  heating  or

domestic hot water request.

Thermostat safety

block

To prevent overheating of the water-gas heat exchanger if the pump is blocked or due to

little  circulation  in  the  primary  circuit,  when  the  CH  NTC  flow  probe  (B1)  detects  an

increase in the temperature exceeding 5 °C per second (for more than 2 consecutive seconds)

the burner is switched off.

Re-start takes place when the flow temperature falls below 43°C.

Insufficient circulation

To prevent overheating of the water-gas heat exchanger, at the end of each CH request (room

thermostat opening), DHW, anti-freeze or "chimney sweep" request, the boiler pump (M1)

continues working for 30 seconds.

Boiler pump post-

circulation

If within 10 seconds from the start of the ignition cycle, the detection electrode (E2) has

not detected flame presence on the burner, boiler functioning is blocked.

The integrated P.C.B. makes 2 ignition attempts with duration of 10 seconds, intervalled

by a time of 30 seconds, after which it blocks.

To  re-start  the  appliance,  press  the  “Reset”  button  and  then  make  a  central  heating  or

domestic hot water request.

N.B.:

it is possible to reset the anomaly up to 5 consecutive times, after which the function

is disabled for at least one hour and one attempt is allowed after every hour; or 5 attempts

can be gained by shutting off the power supply to the circuit.

No ignition

block
