33

STMiE3E ed 09/11

MINI EOLO 3 E

Technical Documentation

Technical Documentation

Outputs

It is powered by the integrated P.C.B. when there is a DHW, CH or anti-freeze request.

Boiler pump

(M1)

This is controlled by the integrated P.C.B. with a high voltage signal (greater than 16 kV)

which causes an electric spark that ignites the air-gas mixture.

Ignition and detection

electrode

(E3)

230 V AC high voltage circuit

Ignition and detection

electrode

(E3)

Inputs

The board power supply is connected to the L and N clamps of the X1 connector.

- 230 V AC +10% / -15%

- 50 Hz +/- 5%

230 V / 50 Hz

Detects  the  ignition  of  the  burner  by  which  the  flame  is  hit  and

allows the integrated P.C.B. to increase the modulation coil speed

(Y2) after having limited it during the ignition phase. It keeps the

gas valve open (Y1).

It is connected to the detection circuit of the integrated P.C.B.

Flame signal =

6 ÷ 15 microA

It is powered by the integrated P.C.B. when burner ignition is necessary.

The SIT 845 gas valve is powered by the mains voltage, the VK 4105 gas valve is powered

by the straight mains voltage through a diode bridge (U1) contained inside the gas valve

connector.

Allows the passage of gas to the burner.

Gas valve (Y1)

(main coils)

The  P.C.B.  is  always  powered  independently  from  the  position  of  the

  button  (see

integrated P.C.B. functioning).

Integrated P.C.B.

Guarantees the flow of air in the sealed chamber and allows the combustion products to

be expelled.

It is powered by the integrated P.C.B.

Fan

(M20)

It allows the diversion of the water flow of the primary circuit to the plate heat exchanger

and vice versa.

It is powered by the integrated P.C.B.

Three-way valve

(M30)

(X 24 version optional)

It cuts off the power supply to the circuit when the current absorbed

exceeds 3.15A.

It is mounted onto the integrated P.C.B.

Phase fuse (F1)

Fuse

3.15 AF 250 V

Safety devices
