  2.6  PARAMETERS AND INFORMATION MENU

Pressing the “MENU” button (2), the display cyclically shows the “Data” menu, “User” menu and a menu protected by a “0000” access
code with the first flashing digit reserved for a qualified technician.
To access an individual menu, once it appears, press the “OK” button (1).
To scroll through the menu items and to edit the values, use the heating temperature control buttons (5). Pressing the “OK” button (1)
confirms the parameter, while pressing the “ESC” button (3) goes back to the previous menu or exits.
A minute after the last operation, the system automatically exits any of the menus.

The menus of the control panel, found in the booklet, refer to rev. 4.0 of the P.C.B. firmware.

Data Menu.

Parameter ID

Description

Range

D 03

Storage tank unit temperature (if paired with a storage tank unit)

-10 ÷ 130 °C

D 04

Value calculated for system setting

5 ÷ 65 °C

D 05

Set value for the DHW set (if paired with a storage tank unit)

10 ÷ 65 °C

D 06

Outdoor temperature (if the outdoor unit external probe is connected or if the optional external
probe is available)

- 20 ÷ 50 °C

D 08

System return water temperature

-10 ÷ 130 °C

D 09

List of the last five anomalies (to scroll the list press “OK” (1)).

-

D 10

Anomaly list reset. Once “D 10” is displayed, press “OK”.

-

D 14

Circulator pump flow rate

0 ÷ 9999

D 20

System flow temperature

-10 ÷ 130 °C

D 22

DHW 3-way (DHW = domestic hot water, CH = central heating) (if paired with a storage tank
unit)

DHW- CH

D 24

Chiller circuit liquid temperature

-10 ÷ 130 °C

D 25

Zone 2 flow temperature (if configured)

-10 ÷ 130 °C

D 26

Probe for primary solar storage (puffer)

-10 ÷ 130 °C

D 28

System circulator pump instantaneous speed

0 ÷ 100 %

D 31

DHW integration function (if paired with a storage tank unit)

OFF - ON

D 32

System integration function

OFF - ON

D 34

Heat pump disabling

OFF - ON

D 35

Solar system inlet

OFF - ON

D 36

Not Used

-

D 41

Relative humidity zone 1 (if zone 1 humidity sensor active)

0 ÷ 99 %

D 42

Relative humidity zone 2 (if zone 2 humidity sensor active)

0 ÷ 99 %

D 43

Zone 1 humidistat (if zone 1 humidistat active)

OFF - ON

D 44

Zone 2 humidistat (if zone 2 humidistat active)

OFF - ON

D 45

Dehumidifier zone 1

OFF - ON

D 46

Dehumidifier zone 2

OFF - ON

D 47

Zone 1 circulator pump

OFF - ON

D 48

Zone 2 circulator pump

OFF - ON

D 49

Central heating / cooling system separation 3-way (CL = cooling, HT = heating)

CL - HT

D 51

Zone 1 remote panel

OFF - ON

D 52

Zone 2 remote panel

OFF - ON

D 53

System setting with remote connection in zone 1

5 ÷ 65 °C
