4

| English

■

Carefully pour the fuel mixture into the tank. Avoid
spillage.

■

Prior to replacing the fuel cap, clean and inspect the
gasket.

■

Immediately replace the fuel cap and hand tighten it.
Wipe away any fuel spillage.

NOTE:

 It is normal for the engine to emit smoke during and

after the

fi

 rst use.

ADDING CHAIN LUBRICATING OIL

See page 319.

 WARNING

Never work without chain lubricant. If the saw chain is
running without lubricant, guide bar and saw chain can
be damaged. It is therefore essential to check the oil
level frequently and every time before starting to use the
product.

1. Clear surface around the oil cap to prevent

contamination.

2.  Unscrew and remove the cap from the oil tank.
3.  Pour the oil into the oil tank and monitor the oil level

gauge. Ensure that no dirt enters the oil tank while
filling.

4.  Put the oil cap back on and tighten. Wipe away any

spillage.

5.  One full oil tank will enable you to use the product for

20- 40 min.

NOTE:

 A properly functioning chain and bar lubricating

system will normally discharge oil from the chain during use.
To check the functionality of the chain and bar lubricating
system, point the tip of the chain at a light coloured surface,
such as a newspaper. A distinct line of oil splatter should be
observed after a short time.

Recommended chain lubricating oil

■

The manufacturer recommends you use only Ryobi
chainsaw lubricating oil. (Available from your authorised
service centre)

STARTING THE PRODUCT

Starting the product differs depending on whether the
engine is cold or warm.

 WARNING

Keep your body to the left of the chain line. Never
straddle the saw or chain, or lean over past the chain
line.

■

Place the product on level ground and ensure that no
objects or obstructions are in the immediate vicinity that
could come in contact with the bar and chain.

■

Hold the front handle firmly with your left hand and put
your right foot onto the base of the rear handle.

To start a cold engine:

See page   317 - 319.

1.  Turn ignition switch to the “on“ position.

2.  Make sure the chain brake is in the brake position by

pushing forward on the lever/hand guard.

3.  Fully press and release the primer bulb at least 10

times.

4.  Pull the choke lever all the way out to the full-choke

position.

5.  When the temperature is above 10°C, pull the starter

grip until the engine attempts to start, but no more than
3 times. When the temperature is below 10°C, pull the
starter grip until the engine attempts to start, but no
more than 5 times.

6.  Push the choke lever all the way in.
7.  Pull starter grip until engine starts.
8.  Depress the trigger release and squeeze the throttle

trigger, then release the throttle trigger to return the
engine to idle.

9.  Allow the product to run idle for 15 - 30 seconds.
10. Before accelerating the engine or cutting wood, make

sure the chain brake is in the “

run

“ position by pulling

back on the brake lever/hand guard.

 CAUTION

Failure to fully release the throttle when chain brake lever
is in the brake position will result in serious damage to
the product. Never squeeze and hold the throttle trigger
while the chain brake is in the brake position.

To start a warm engine:

See page 327.

1.  Turn the ignition switch to the “on“ position.
2.  Make sure the chain brake is in the brake position by

pushing forward on the lever/hand guard.

3.  Pull the choke lever all the way out to the full-choke

position and then push it all the way in.

4.  Pull starter grip until engine runs, but no more than 5

times. Depress the trigger release and squeeze the
throttle trigger, then release the throttle trigger to return
the engine to idle. If engine does not start after 5 pulls,
use cold engine starting procedure.

5.  Before accelerating the engine or cutting wood, make

sure the chain brake is in the “run“ position by pulling
back on the brake lever/hand guard.

STOPPING THE ENGINE

Release the throttle trigger and let the engine return to idle.
To stop the engine, move the ignition switch to the

stop

(0) position. Do not put the product on the ground when
the chain is still moving. For additional safety, set the chain
brake when the product is not in use.
In the event that the ignition switch will not stop the product,
pull the choke lever out to the fully extended position (

Full

Choke

) and engage the chain brake to stop the engine.

If the ignition switch will not stop the product when set to
the

stop

 position, have the ignition switch repaired before

using the product again to prevent unsafe conditions or
serious injury.

NOTE:

When you are

fi

 nished using the product, always

relieve tank pressure by loosening, then retightening, the
chain lubricant and fuel caps. Allow the engine to cool down
before storing.
