βη

CHECKING THE SPARK PLUG



τnly use the supplied universal wrench to remove or to install the spark plugέ



The gap between the two electrodes of the spark plug should be ίέι – ίέκ mm

(ίέίβκ" – ίέίγβ")έ If the gap is too wide or too narrow, adjust itέ If the spark plug

is clogged or contaminated, clean it thoroughly or replace itέ

Place the plug cap properly as illustrated after checkingέ

 CAUTIONμ



σever touch the spark plug connector while the engine is running (danger

of high voltage electric shock)έ

SUPPLY OF GREASE TO GEAR CASE



Supply grease (Shell Alvania β or equivalent) to the gear case (1) through the

grease hole (β) every βη hoursέ (ύenuine εAKITA grease may be purchased

from your εAKITA dealerέ)

(1)

(2)

SUPPLY OF GREASE TO THE FLEXIBLE SHAFT

1έ  By  performing  the  steps  in  “ετUσTIσύ  τό  όδEXIBδE  SώAόT”  in  reverse,

remove the clamps (γ pieces), and disconnect the lead units (β pieces) and
the control cableέ

NOTEμ



Use a slotted screwdriver etcέ for opening the connectorέ

βέ  Remove  the  lexible  shaft  from  the  clutch  case  and  the  straight  shaftέ  To

remove the lexible shaft from the clutch case, pull up the knob and remove
itέ  To  remove  the  lexible  shaft  from  the  straight  shaft,  remove  the  bolt  and
remove itέ

γέ  Pull out the inner shaft (1) from the lexible liner (β), and apply grease (Shell

Alvania  β  or  equivalent)  (γ)  on  the  inner  shaft  for  every  βη  hoursέ  (ύenuine
εAKITA grease may be purchased from your εAKITA dealerέ)

ζέ  Refer  to  the  steps  in  “ετUσTIσύ  τό  όδEXIBδE  SώAόT”,  reassemble  the

lexible shaft, control cable, lead units (β pieces), and clamps (γ pieces)έ

NOTICEμ



The lexible shaft may be broken if no grease is appliedέ



όor  extending  service  life  of  the  parts,  reinstall  each  end  of  the  lexible

shaft onto the opposite side, iέeέ formerly engine side onto the control lever

sideέ

ίέι mm – ίέκ mm

(ίέίβκ" – ίέίγβ")

(1)

(3)

(2)
