Inspection and reill of engine oil

●

Perform the following procedure, with the engine cooled downέ

●

Assure that the engine is on a lat horizontal surface and conirm if the oil level

is between the lower (1) and upper (β) limit of the oil indicatorέ

●

If the oil level is below the lower limit, remove the oil cap and add oilέ

●

The area surrounding the external marks is transparent, so the amount of oil

inside  can  be  checked  without  having  to  remove  the  oil  capέ  ώowever,  if  oil

pipe becomes extremely dirty, visibility may be lost, and oil level will have to be

checked against stepped section on inside of oil pipeέ

●

You  may  need  to  reill  oil  approximately  every  1ί  operating  hours  (every  1ί

refuellings)έ

If the oil changes in color or mixes with dirt, replace it with new oneέ (όor the

interval and method of replacement, refer to P βγέ)

BEFORE START OF OPERATION

(1) Keep the engine level, and detach the oil capέ

(β) όill with oil to upper limit markέ

Use oil bottle when illingέ

(1)

(2)

Recommended oilμ

SAE 1ίWάγί oil of API Classiication, Class Sό or higher (ζάstroke engine for automobile)

Oil volumeμ

Approxέ ίέ1ίδ

NOTEμ

●

If the engine is not positioned as illustrated on a horizontal surface, an inaccurate indication of oil level may occur and oil may be overilledέ

όilling oil above the upper limit may cause oil contamination andήor white smokeέ

Replacement of oilμ “Oil cap”

●

Remove dust or dirt near the oil reill port, and detach the oil capέ

●

Keep the detached oil cap free of sand or dustέ τtherwise, any sand or dust adhering to the oil cap may cause irregular oil circulation or wear

on the engine parts, which will result in troublesέ

(γ) Securely tighten the oil capέ Insuficient tightening may cause oil leakageέ
