β1

Replacing the nylon cord (BUεP & FEED)

 WARNINGμ

●

εake  sure  that  the  cover  of  the  nylon  cutting  head  is  secured  to  the

housing properly as described belowέ όailure to properly secure the cover

may cause the nylon cutting head to ly apart resulting in serious personal

injuryέ

1έ  Press the latches (1) on the housing (β) inwards and lift upward to remove the

cover (γ)έ

βέ  Release  the  nylon  cord  from  the  eyeletέ And  remove  the  spool  (ζ)  from  the

coverέ

Discard any of the remaining nylon cordέ

 CAUTIONμ

●

The cutting tools shown in the illustration are not to be sharpenedέ εanual

resharpening will result in imbalances of the cutting tool causing vibrations

and damage to the equipmentέ

NOTEμ

●

To increase the service life of the cutter blade it may be turned over once,

until both cutting edges have become bluntέ

RESHARPENING THE CUTTING TOOL

NYδON CUTTING HEAD

The  nylon  cutting  head  is  a  dual  line  trimmer  head  that  has  bump  &  feed

mechanismέ

The nylon cutting head feeds out the nylon cord after tapping the trimmer head

on the groundέ

Operation

●

Increase the nylon cutting head speed to approxέ θ,ίίί min

–1

έ

Bump the nylon cutting head lightly on the groundέ

●

The most effective cutting area is shown by the shaded areaέ

●

If the nylon cord does not feed out, rewindήreplace the nylon cord by following

the procedures described under “Replacing the nylon cordέ”

γέ  ώook the middle of the new nylon cord to the notch (η) located at the center of

the spool between the β channelsέ

τne side of the cord should be about κί mm (γ") longer than the other sideέ

Wind both ends irmly around the spool in the direction of arrow mark on the

spoolέ

εost effective cutting area

(1)

(3)

(2)

(4)

(3)

(5)

κί mm (γ")
