βγ

 CAUTIONμ

●

Before doing any work on the equipment, always stop the engine and pull the plug cap off the spark plug (see “checking the spark plug”)έ

Always wear protective gloves!

To ensure a long service life and to avoid any damage to the equipment, the following servicing operations should be performed at regular intervalsέ

Daily checkup and maintenance

●

Before  operation,  check  the  machine  for  loose  screws  or  missing  partsέ  Pay  particular  attention  to  the  tightness  of  the  metal  blade  or  nylon

cutting headέ

●

Before operation, always check for clogging of the cooling air passage and the cylinder insέ

Clean them if necessaryέ

●

Perform the following work daily after useμ

–

Clean the equipment externally and inspect for damageέ

–

Clean the air ilterέ When working under extremely dusty conditions, clean the ilter the several times a dayέ

–

Check the blade or the nylon cutting head for damage and make sure it is irmly mountedέ

–

Check  that  there  is  suficient  difference  between  idling  and  engagement  speed  to  ensure  that  the  cutting  tool  is  at  a  standstill  while  the

engine is idling (if necessary reduce idling speed)έ

If under idling conditions the tool should still continue to run, consult your nearest Authorized Service Agentέ

●

Check the functioning of the Iάτ switch, the lockάoff lever and the throttle leverέ

SERVICING INSTRUCTIONS

REPδACEεENT OF ENGINE OIδ

Deteriorated engine oil will shorten the life of the engineέ Be sure to check the oil and level regularlyέ

WARNINGμ The engine and engine oil is still hot just after stopping engine. Allow suficient time for the engine and engine

oil to cool down. Otherwise a skin burn may result.

NOTEμ

●

If the oil illed above the limit, it may  be contaminated or may  catch ire with white smoke. Allow suficient time after  stopping

engine for the engine oil to return to the oil tank to ensure accurate reading of the oil level.

Interval of replacementμ

After irst βί operating hours, followed by every ηί operating hoursέ

Recommended oilμ

SAE1ίWάγί oil of API Classiication Sό Class or higher (ζάstroke engine oil for automobile)

In replacement, perform the following procedureέ
1)  εake sure that the fuel tank cap is tightened securelyέ
β)  Place large container (pan, etcέ) under drain holeέ
γ)  Remove drain bolt (1) and then remove oil cap (β) to drain out oil from drain

hole (γ)έ

At this time, be sure not to lose drain bolt’s gasket (ζ), or get dirty any of the

removed componentsέ

ζ)  τnce  all  the  oil  has  been  drained,  install  gasket  and  drain  bolt,  and  tightly

secure drain bolt, so that it will not loosen and cause leaksέ

[Tightening torqueμ η σ•m]

*

Use cloth to fully wipe off any oil attached to bolt and equipmentέ

Alternative draining method

Remove oil cap, tilt the equipment toward oil iller hole, and drain out oilέ

Collect oil in containerέ

(1)

(4)

(3)

(2)
