To meet the applicable safety provisions, only the toolήprotector combinations as indicated in the table must be usedέ

MOUNTING OF PROTECTOR

 CAUTIONμ

●

The  appropriate  protector  must  always  be  installed,  for

your  own  safety  and  in  order  to  comply  with  accident

prevention regulationsέ

τperation  of  the  equipment  without  the  guard  being  in

place is not permittedέ

Do not apply other combination when using sawάbladeέ

NOTEμ

●

The  standard  combination  of  cutting  tool  differs  from

county to countryέ

For metal blades

CAUTIONμ

●

εake sure that the protector tightening bolts are tightened evenly so that

the gap between the clamp and the protector will be constantέ

τtherwise, the protector sometimes may not function as speciiedέ

(For Type A protector)

όix the protector (γ) to the clamp (β) with two bolts εθxγί (1)έ

(For Type B protector)

όix the protector to the clamp (ζ) with two bolts εθx1κ (η)έ

If the protector cover (θ) is installed on the shaft, remove it irst as followsέ
1έ Remove the washers (ι), bolts εθxγί (κ) from protector coverέ
βέ Remove the protector cover by slightly spreading the in (λ)έ

NOTEμ

●

When changing the protector from Type B to Type A, install the protector

cover,  bolts  εθxγί  and  washers  onto  the  shaft  before  installing  the

protectorέ

(1)

(3)

(2)

εetal blade

Protector for metal blade

Type A

Type B

σylon cutting head

Protector for

nylon cutting head

Type A

(5)

(4)

(9)

(6)

(8)

(7)
