εounting the lexible shaft

1έ  Remove the bolt (1) from the end of the straight shaft (β)έ
βέ  Remove the cap from the lexible shaftέ

NOTEμ



Do not lose the capέ Always put the cap when removing the lexible shaftέ

γέ  Turn  the  lexible  shaft  so  that  the  dented  part  (γ)  of  the  lexible  shaft  faces

downwardsέ

ζέ  Align  the  square  inner  shaft  (ζ)  with  the  joint  hole  (η)έ  Insert  the  end  of  the

lexible shaft into the pipe holder all the wayέ

ηέ  Tighten them with the bolt (1)έ

NOTICEμ



If  it  is  dificult  to  insert  the  lexible  shaft,  align  the  square  inner  shaft  (ζ)

againέ



Do not pull out the inner shaft more than γη mm (1ά1ήγ")έ

MOUNTING OF FLEXIBLE SHAFT

θέ  Align  the  hole  (ι)  on  the  other  end  of  lexible  shaft  with  the  knob  (κ)  of  the

clutch case (θ), and insert the lexible shaft into the clutch caseέ

ιέ  εake sure the knob clicks as the knob its into the hole of the lexible shaftέ

To remove the lexible shaft from the clutch case, pull up the knob and remove itέ

Connecting the control cable

1έ  όit the end of the control cable from the control lever (β) onto the end of the

control cable from the engine (γ)έ

βέ  Place the control cable from the control lever in the connector (1)έ And then

close the connectorέ

γέ  εake  sure  the  throttle  in  the  carburetor  moves  simultaneously  when  pulling

the throttle leverέ

(1)

(3)

(2)

Connecting the lead unit

Connect  the  lead  units  from  the  engine  (1)  with  the  lead  units  from  the  control

lever (β) as each male and female terminals are connectedέ

(1)

(2)

Securing the control cable

Secure  the  control  cable  (1)  to  the  lexible  shaft  by  using  two  clamps  (β)  and

another clamp (γ) as illustratedέ

 CAUTIONμ



εake sure the control cable is attached to the lexible shaft properlyέ δoose

cable may catch the branches etcέ and result in personal injuryέ



Do  not  twine  the  control  cable  around  the  lexible  shaftέ  τtherwise  the

throttle may not work properlyέ

(1)

(4)

(3)

(2)

(5)

(6)

(8)

(7)

(1)

(3)

(2)
