12

Be very careful when using the grass trimmer for vertical trimming

of lawns and flower bed edges. Stay away from the plane of cutting

line rotation to avoid risk of being hit with an object projected by the

cutting line.

ROTATABLE MAIN HANDLE

Rotation of main handle in relation to the head by 90° clockwise or

counter-clockwise allows to trim flower bed and lawn edges vertically.

•

Hold the trimmer body and pull the telescopic pipe (

9

) and rotate it

clockwise or counter-clockwise (follow the signs located on the ring).

•

Release the pressure, and the spring action will make the telescopic

pipe (

9

) with the main handle (

7

) lock in the selected position (

fig. J

).

OPERATION / SETTINGS

SWITCHING ON / OFF

The grass trimmer switch features protection against accidental start

up.

Switching on

 – press the switch lock button (

6

) and press the switch

button (

5

) (

fig. K

).

Switching off

 – release pressure on the switch button (

5

).

Cutting parts rotate for some time after the motor is switched off.

Never attempt to lock the switch in the ON position.

All parts must be assembled properly and must fulfil requirements

that ensure appropriate and safe grass trimmer operation. Any

damaged protective element or part must be repaired or replaced

immediately.

GUIDELINES FOR SAFE AND EFFICIENT USE

•

When trimming long grass perform the work gradually, by layers.

•

Keep the grass trimmer away from hard objects and cultivated plants.

•

Operate the grass trimmer only when the grass is dry.

•

When trimming edges drive the tool along lawn edge.

OPERATION AND MAINTENANCE

Remove the battery from the device before commencing any

activities related to installation, adjustment, repair or maintenance.

MAINTENANCE AND STORAGE

•

Cleaning the device after each use is recommended.

•

Clean ventilation holes in engine casing regularly.

•

Remove grass residues from the guard and the head regularly.

•

Never clean the device with water, aggressive fluids or solvents.

•

Clean the device with brush or delicate cloth.

•

Store the device in a dry place, beyond reach of children.

•

Store the device with the battery removed.

REPLACEMENT OF CUTTING PARTS

The grass trimmer is supplied with 20 spare cutting parts that are

attached to the auxiliary handle. Use only recommended cutting parts.

•

Put larger hole of the cutting part (

12

) over the pin (

22

) of the head

(

13

) and pull outwards, so the pin (

22

) is in the smaller hole of the

cutting part (

12

) (

fig. L

).

•

Repeat the action for the second cutting part.

•

Removal of the cutting part (

12

) is similar to installation, only the

sequence of actions is reversed.

All defects should be repaired by service workshop authorized by the

manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Cordless Grass Trimmer 58G030

Parameter

Value

Battery voltage

18 V DC

Spindle rotational speed with no load

9000 min

-1

Cutting width

254 mm

Polymer blades

88,5 mm

Number of blades attached to the

head

2

Handle length adjustment

1,1 ÷1,4 m

Protection class

III

Weight

1,8 kg

Year of production

2021

58G030 defines type and indication of the device

Graphite Energy+ System Battery

Parameter

Value

Battery

58G001

58G004

Battery voltage

18 V DC

18 V DC

Battery type

Li-Ion

Li-Ion

Battery capacity

2000 mAh

4000 mAh

Ambient temperature range

4

0

C – 40

0

C

4

0

C – 40

0

C

Charging time for charger 58G002

1 h

2 h

Weight

0,400 kg

0,650 kg

Year of production

2021

2021

Graphite Energy+ System Charger

Parameter

Value

Charger type

58G002

Supply voltage

230 V AC

Power supply frequency

50 Hz

Charging voltage

22 V DC

Max. charging current

2300 mA

Ambient temperature range

4

0

C – 40

0

C

Charging time of the battery 58G001

1 h

Charging time of the battery 58G004

2 h

Protection class

II

Weight

0,300 kg

Year of production

2021

NOISE LEVEL AND VIBRATION PARAMETERS

Sound pressure

L

PA

 = 79,5 dB(A) K=3dB(A)

Sound power

L

WA

 = 91,9 dB(A) K=2,23dB(A)

Vibration acceleration (main

handle)

a

h

 = 1,453 m/s

2

 K=1,5 m/s

2

Vibration acceleration (auxiliary

handle)

a

h

 = 3,224 m/s

2

 K=1,5 m/s

2

Noise and vibration information

Noise produced by the device is defined with: level of produced sound

pressure L

PA

 and level of sound power L

WA

(where K is measurement

uncertainty). Vibrations produced by the device are defined with

vibration acceleration value a

h

(where K is measurement uncertainty).

Sound pressure L

PA

, sound power L

WA

and vibration acceleration a

h

specified in this manual have been measured in accordance with the

standard EN 60335-1:2012; EN 50636. Specified vibration level a

h

can

be used to compare tools and for initial evaluation of exposition to

vibrations.

Specified vibration level is typical only for the main applications of the

device. When the device is used for other purposes or with different

working tools, the vibration level may change. Insufficient or too rare

maintenance may increase vibration level. The abovementioned factors

may lead to higher exposure to vibrations during whole working time.

In order to precisely define exposure to vibrations, include periods

when the device is switched off and when it is switched on but not

used for working. Once all factors have been carefully considered,

total exposition to vibrations may be significantly lower.

To protect the user from results of exposure to vibrations, use additional

safety measures such as: device and working tool periodic maintenance,

proper hand temperature conditions, good work organisation.

ENVIRONMENTAL PROTECTION

Electrical equipment must not be disposed off with household

waste and, instead, should be utilized at appropriate facilities.

Information on utilization can be provided by the product

vendor or the local authorities. Waste electrical and electronic

equipment contains substances that are not neutral to

the natural environment. Equipment that is not recycled

constitutes a potential hazard to the environment and to

human health.

Li-Ion

Storage batteries/batteries must not be disposed with

domestic waste, put in a fire or into the water. Damaged

or used up storage batteries must be properly recycled in

compliance with the current directive pertaining to disposal of

storage batteries and batteries.

* Right to introduce changes is reserved.
