9

RQT7448

G

e

tt

in

g

 st

ar

te

d

≥

Decoder here means the device used to decode scrambled broadcasts (Pay TV).

≥

Change the “AV2 Input” and “AV2 Connection” settings in the SETUP menu to match the connected equipment (

➡

page 44) after tuning is

completed (

➡

page 10, 11).

Viewing video from the decoder on the television while the
unit is stopped, or while recording

If you connected the television to the AV1 terminal and the decoder
to the AV2 terminal on this unit, press [0]

i

[ENTER]. (“DVD”

appears on the unit’s display.)
Press again to cancel. (“TV” appears on the unit’s display.)

≥

If the television is compatible with RGB input, the RGB output

signal from the decoder can also be output from the main unit the
same way.

∫

To enjoy multi-channel surround sound on
DVD-Video

Connect an amplifier with Dolby Digital, DTS and MPEG decoders
using an optical digital audio cable and change the settings in
“Digital Audio Output” (

➡

page 43) after tuning is completed

(

➡

page 10, 11).

≥

You cannot use DTS Digital Surround decoders not suited to DVD.

≥

Even if using this connection, output will be only 2 channels when

playing DVD-Audio.

∫

Connection to a stereo amplifier

Connecting a satellite receiver, digital receiver or decoder

P

R

RF IN

RF OUT

COMPONENT

VIDEO OUT

P

B

Y

AV1  (TV)

AV2  (DECODER/EXT)

(PROGRESSIVE/
 INTERLACE)

AV OUT

Satellite receiver,
digital receiver or
decoder’s rear panel

21-pin Scart cable

This unit’s
rear panel

Connecting an amplifier or system component

R - AUDIO -

R - AUDIO -

OPTICAL

DIGITAL AUDIO OUT

(PCM/BITSTREAM)

AC IN

OPTICAL IN

Optical digital audio cable

Do not bend this cable sharply.

Insert fully, with this side facing up.

This unit’s rear panel

Amplifier’s rear panel

R - AUDIO - L

VIDEO S-VIDEO

R - AUDIO - L

VIDEO S-VIDEO

OPTICAL

OUT

AV
4

 I

N

DIGITAL AUDIO OUT

(PCM/BITSTREAM)

AUDIO IN

R      L

Audio cable

Red White

Red White

This unit’s rear panel

Amplifier’s rear panel

Do not place the unit on
amplifiers or equipment
that may become hot.

The heat can damage the unit.
