6

RQT7448

G

e

tt

in

g

 st

ar

te

d

STEP

1

Connection

≥

The equipment connections described are examples.

≥

Before connection, turn off all equipment and read the appropriate operating instructions.

≥

Peripheral equipment and optional cables sold separately unless otherwise indicated.

∫

Recommended connection for your television

Q Link functions

Q Link offers a range of convenient functions (For further details

➡

page 50). Make sure to connect a fully wired 21-pin Scart cable to the

television if using the Q Link function.
The following systems from other manufacturers have similar function to Q Link from Panasonic. For details, refer to your television

’

s operating

instructions or consult your dealer.

≥

Q Link (registered trademark of Panasonic)

≥

DATA LOGIC (registered trademark of Metz)

≥

Easy Link (registered trademark of Philips)

≥

Megalogic (registered trademark of Grundig)

≥

SMARTLINK (registered trademark of Sony)

∫

Examples of equipment you can connect to this unit’s terminals

∫

Do not connect the unit through a video cassette recorder

Video signals fed through video cassette recorders will be affected by copyright
protection systems and the picture will not be shown correctly on the television.

≥

When connecting to a television with a built in VCR, connect to the input terminals on

the television side, not the VCR side.

∫

When the unit is not to be used for a long time

To save power, unplug it from the household mains socket. This
unit consumes a small amount of power, even when it is turned off
(approx. 3 W).

What kind of input terminal does your television have?

Required

cable(s)

Page No. for

connections

Page No. for TV

settings

Scart

Highly recommended connection.

≥

You can enjoy high-quality RGB video from this

unit by connecting to an RGB compatible
television.

≥

If your television has the Q Link feature, you can

use a variety of useful functions.

Fully wired 21-
pin Scart cable

➡

7

➡

11

≥

If it’s a Q Link

television

➡

10

Component
video

These terminals provide a purer picture than the S-
Video terminal.

≥

If your television is compatible with progressive

scan, you can enjoy high-quality progressive video.
If you have a progressive compatible CRT
television, we cannot recommend this connection
as some flickering may occur.

3 video cables

➡

8

➡

11

S-Video

This terminal achieves a more vivid picture than the
video terminal.

S-Video cable

➡

8

➡

11

Audio/Video

The most basic connection.

Audio/Video
cable (included)

➡

8

➡

11

AV IN

COMPONENT

VIDEO IN

S-VIDEO IN

AUDIO IN

R         L

VIDEO IN

Television

Video cassette recorder

Camcorder

This unit

Amplifier

To AV3 or DV input terminals (front) (

➡

page 35)

To AV2 or AV4 input terminals (rear)

From AUDIO OUT terminals or
DIGITAL AUDIO OUT terminal

From AV1, AUDIO/VIDEO OUT or

COMPONENT VIDEO OUT terminals

Satellite/digital

receiver or decoder

Television

This unit

VCR

Television

This unit

VCR

Before moving the unit, ensure the disc tray is
empty.

Failure to do so will risk severely damaging the disc and
the unit.
