Maintenance and care

441582_a

25

1. Remove the depth skid.
2. Unscrew  the  screw  plug  of  the  fill  opening

(18/1).

3. Tilt the cultivator backwards into position A.
4. Suction up the waste oil with a pump.
5. Fill with new oil. Required oil amount approx.

0.5 l.

6. Measure  the  oil  level  to  check  the  filled  oil

amount:  Tilt  the  cultivator  backwards.  Oil

must flow out of the fill opening just before the

cultivator touches the ground.

7. Screw  the  screw  plug  into  the  fill  opening

(18/1) again.

8. Always  dispose  of  waste  oil  in  accordance

with legal requirements, e.g. at waste oil ac-

ceptance points.

Replacing the gear oil of the gearbox, 7505

V2R (19) (20)

The  gear  oil  of  the  gearbox  must  be  replaced

every  60  working  hours  (amount:  0.9  l,  viscosity

SAE 80). The cultivator must be warm in order to

replace the gear oil.
Check the oil level:
1. Place the cultivator on a level surface.
2. Pull the oil dipstick (19/1) out and check that

the  oil  level  is  between  “Min.”  and  “Max.”.  If

the  oil  level  is  below  the  “Min.”  marking,  oil

must be refilled.

3. Insert the oil dipstick again.
Draining oil:
1. Pull out the oil dipstick (20/1).
2. Place a collecting container (B) with a capa-

city of at least 1 litre under the manual trans-

mission (20/2).

3. Unscrew the oil drain plug (20/3).
4. Allow  the  oil  to  drain  completely  into  the

collecting container (B).

5. Screw in the oil drain plug (20/3) again.
Filling in oil:
1. Fill  the  manual  transmission  with  new  oil

(amount: 0.9 l, viscosity SAE 80) again via the

fill opening (A) of the oil dipstick.

2. Insert the oil dipstick (20/1) again.
3. Check that the oil level is correct (see “Che-

cking the oil level").

Changing the engine oil

See operating instructions of the motor.

Replacing the air filter and spark plug

See operating instructions of the motor.

Readjusting the Bowden cable of the gas le-

ver

See operating instructions of the motor.

Readjust the Bowden cables for the clutch le-

ver and reverse gear (only 7505 VR) (21)

The fine adjustment of a Bowden cable is carried

out  with  the  respective  setscrew  on  the  Bowden

cable ends. One setscrew is on the lever on the

handlebar  and  the  other  at  the  attachment  point

of  the  motor  clutch  or  at  the  attachment  point  of

the motor gearbox.
The travel of the Bowden cable for the tiller blades

must  be  set  in  such  a  way  that  the  tiller  blades

start to turn after the clutch lever (21/1) has travel-

led halfway. If the clutch lever (21/1) or the lever

(21/7)  for  the  reverse  gear  has  been  completely

pressed on the handlebar, the associated tension

spring (21/2) must be pulled apart by 8-10 mm.
1. Loosen the locknut of the setscrew on the re-

spective Bowden cable. For the clutch lever:

(21/3) and (21/4). For the lever of the reverse

gear: (21/5) and (21/6).

2. Turn the setscrew to lengthen or shorten the

travel of the Bowden cable.

3. Tighten the locknut again.

STORAGE

WARNING!
Danger of fire - Danger of serious da-

mage to people and property.

Persons can be seriously injured due to

exploding  fuel  vapours  and  serious  da-

mage to property can occur.

Only store the fuelled appliance in a

well-ventilated area.
Do  not  store  the  fuelled  appliance

in buildings where fuel vapours can

come into contact with open flames

or sparks.
