Translation of the original instructions for use

441582_a

19

TRANSLATION OF THE ORIGINAL

INSTRUCTIONS FOR USE

Contents

About these instructions for use.......................19
Product  description.......................................... 19
Safety  instructions............................................ 20
Installation........................................................ 21
Start-up............................................................. 23
Operation.......................................................... 23
Maintenance  and  care..................................... 24
Storage............................................................. 25
Technical  data.................................................. 26
Help in case of malfunctions............................ 27
EU declaration of conformity............................ 28

ABOUT THESE INSTRUCTIONS FOR

USE

It  is  essential  to  read  through  these  instruc-

tions  for  use  carefully  before  start-up.  This

is essential for safe working and trouble-free

handling.
Always  safeguard  these  instructions  for  use

so that they can be consulted if you need any

information about the appliance.
Only  pass  on  the  appliance  with  these  in-

structions for use to other persons.
Comply with the safety and warning informa-

tion in these instructions for use.

Legends and signal words

DANGER!

Denotes  an  immediately  dangerous  si-

tuation which will result in fatal or serious

injury if not avoided.

WARNING!

Denotes  a  potentially  dangerous  situa-

tion  which  can  result  in  fatal  or  serious

injury if not avoided.

CAUTION!

Denotes  a  potentially  dangerous  situa-

tion  which  can  result  in  minor  or  mode-

rate injury if not avoided.

CAUTION!

Denotes  a  situation  which  can  result  in

material damage if not avoided.

ADVICE

NOTE:  Special  instructions  for  ease  of

understanding and handling.

PRODUCT DESCRIPTION

Designated use

This device is only intended for use on pre-culti-

vated soil.
This  device  is  not  suitable  for  use  on  solid  soil,

e.g. compacted turf.
The  continued  use  of  this  device  with  original

spare parts is only allowed in accordance with its

purpose. Any other use is not permitted.

Product overview

Item

Assemblies

(01/1)

Handlebar

(01/2)

Oil tank

(01/3)

Motor

(01/4)

Petrol tank

(01/5)

Guard plates with optional guard

plate extension

(01/6)

Lateral protective discs

(01/7)

Tiller blades

(01/8)

Transport wheel

(01/9)

Depth skid

Item

Controls

(01/10) Clutch lever
(01/11) Safety button
(01/12) Throttle lever
(01/13) Cam lever for lateral adjustment of

the handlebar

(01/14) Wing nuts for height adjustment of

the handlebar

(01a/15) 7505 VR: Reverse lever
