Start-up

441582_a

23

Mounting the guard plate extension:
1. Place the guard plate extension (11/1) on the

already available guard plate (11/2) as shown

in the figure (11).

2. Attach the guard plate extension to the exis-

ting guard plate with the screws (11/3).

START-UP

Adjusting Bowden cables

See chapter “Maintenance and care".

Adjusting the height of the handlebar (6)

The  height  of  the  handlebar  depends  on  your

body  height.  The  handlebar  should  be  at  waist

height.
1. Turn  both  grips  (06/5)  for  the  height  adjust-

ment of the handlebar open until the handle-

bar can be pressed down or up.

2. Press  the  handlebar  down  or  up  until  it  is  at

the required height.

3. Retighten  both  grips  for  the  height  adjust-

ment.

OPERATION

Fuel fill

See operating instructions of the motor.

Roll the cultivator to the place where it is to

be used (12)

The cultivator is easy to roll to the place of opera-

tion using the transport wheel (12/1).
1. If the transport wheel is folded in: Pull out (di-

rection  A)  the  transport  wheel  (12/1)  on  the

wheel mount (12/2). Fold it down into the drive

position and release it so it can lock in place.

2. Lift the cultivator using the handlebar until it is

on the transport wheel (12/1).

3. Push the cultivator to the place of operation.
4. Folding  in  the  transport  wheel  for  tilling:  Pull

out (direction A) the transport wheel (12/1) on

the wheel mount (12/2). Fold it upwards into

the horizontal position and release it so it can

lock in place.

Starting and stopping the motor (14)

Starting the motor:
1. Open  the  petrol  cock  by  pushing  the  lever

(14/1) in the ON arrow direction.

2. If the motor is cold:

Push  the  choke  lever  (14/2)  towards  the

choke symbol. Only use this position for star-

ting the motor.

3. Adjusting the motor speed or work speed:

Increasing the work speed: Push the control-

ler  (14/3)  for  the  motor  speed  in  the  “MAX.

(Hare)” direction.

Decreasing  the  work  speed:  Push  the  con-

troller (14/3) for the motor speed in the “MIN.

(Tortoise)” direction.

4. Rotate the gas lever (14/4) to position “1”.

In position “1” the motor runs at the speed set

on the controller. The motor does not start in

position “0”.

5. Use the grip (14/5) to quickly pull out the star-

ter  rope  and  then  let  it  slowly  roll  up  again.

The motor starts to run.

If the motor does not run: Check that all pre-

vious  work  steps  have  been  carried  out  and

then pull the starter rope again.

6. When  the  motor  is  running  smoothly:  Slowly

push the choke lever (14/2) back to the stop.

If the motor starts stuttering, push the choke

lever slightly back in the direction of the choke

symbol.

Stopping the motor:
1. Rotate the gas lever (14/4) to position "0".
2. Close the petrol cock (14/1).

Starting and stopping the tiller blades (13)

Starting the tiller blades:
1. Hold the handlebar by the grip (13/1).
2. Press the safety button (13/2).
3. Press the clutch lever (13/3) on the handlebar

firmly downwards.

After the lever has travelled halfway, the tiller bla-

des  begin  to  rotate  and  the  cultivator  starts  mo-

ving. After the clutch lever has been pressed fully

downwards,  the  tiller  blades  have  been  comple-

tely started.
Stopping the tiller blades:
1. Release the clutch lever (13/3).
The cultivator stops.
