en

Operation

24

7505 VR / 7505 V2R

Use the depth skid

When  the  handlebar  of  the  cultivator  –  and  thus

also the depth skid – is pressed down, the speed

of the cultivator decreases or it stops.
When  the  handlebar  of  the  cultivator  –  and  thus

also the depth skid – is lifted upwards, the speed

of the cultivator increases.

Engaging/releasing reverse gear, 7505 VR

(15)

1. To  stop  the  tiller  blades:  Release  the  clutch

lever (15/3).

2. Pull the lever (15/4) for reverse gear upwards

up to the stop.

3. To start the tiller blades: Press the safety but-

ton  (15/2)  and  firmly  press  the  clutch  lever

(15/3) on the handlebar (15/1) downwards.

Operating the gear shift, 7505 V2R (16)

The  gear  lever  (16/1)  can  be  used  to  switch  2

forwards gears and 1 reverse gear. The first for-

wards gear is intended for hard ground; the tiller

blades  turn  slowly.  The  second  forwards  gear  is

intended for less hard ground; the tiller blades turn

faster.
1. To  stop  the  tiller  blades:  Release  the  clutch

lever (16/3).

2. Turn the gear lever (16/1) in such a way that it

coincides with the required gear on the plate

(16/2) for the gear display (1 = 1st gear, 2 =

2nd gear, R = reverse gear).

3. To start the tiller blades: Press the safety but-

ton  (16/4)  and  firmly  press  the  clutch  lever

(16/3) on the handlebar downwards.

Adjusting the sideways position of the hand-

lebar (17)

Sideways  adjustment  of  the  handlebar  makes  it

possible  not  to  walk  on  the  surface  already  pro-

cessed. The handlebar can be adjusted by 35° to

either side.
1. Pull  the  cam  lever  (17/1)  upwards.  The

handlebar (17/2) disengages from the holder

(17/3).

2. Turn  the  handlebar  (17/2)  to  the  side  (left  or

right) up to the stop and keep it in this position.

3. Press the cam lever (17/1) down. The hand-

lebar (17/2) is locked in place.

MAINTENANCE AND CARE

WARNING!
Danger of serious injury during main-

tenance and care work!

Persons can be seriously injured by mo-

ving machine parts.

Always switch the motor off and pull

the spark plug connector prior to any

maintenance and care work.
Motor  may  continue  running.  After

switching off, make sure that the mo-

tor has stopped.
Always wear work gloves when car-

rying out maintenance and care jobs

on the tiller blades.

Clean the appliance after every use.
Do not spray the machine with water! Pene-

trating  water  (ignition  system,  carburettor...)

can lead to malfunctions.

ADVICE

When the device is tilted to the side, the

carburettor must be pointing upwards.

CAUTION!
Danger of pollution due to waste oil

Waste oil that is illegally disposed of, e.g.

in  the  sewage  system,  in  the  ground  or

in water, can cause serious pollution.

Always  dispose  of  waste  oil  in  ac-

cordance  with  legal  requirements,

e.g. at waste oil acceptance points.

Every point of sale that sells oil is le-

gally bound to accept waste oil.
Never  drain  waste  oil  into  the  se-

wage system, the ground or into wa-

ter.

Expert inspection is required:

After running into an obstacle
If the motor stops suddenly
If there is gear damage
If the V-belt is defective
If a blade is bent
If the motor shaft is bent

Replacing the gear oil of the chain gear (18)

The  gear  oil  of  the  chain  gear  must  be  replaced

every 100 working hours (amount: 0.5 l, viscosity

SAE 80). The cultivator must be warm in order to

replace the gear oil.
