1. Maximum speed

 (about 5 Km/h).

2. Minimum speed

 (about 2.5 Km/h).

NOTE

 The last speed level selected remains

set after the machine is turned off.

IMPORTANT

 To prevent damage to

the transmission, do not pull the machine

backwards with the drive engaged.

 5.5  “ECO” BUTTON

The “ECO” mode allows to save energy when

cutting the grass, optimising the battery life.

Press the button (Fig.7.D) to enable

or disable “ECO” mode.

When the traction is active, the display

shows the indication "E".

This function automatically switches off when

the operator presence levers are released.

NOTE

 It is not recommended to use the

“ECO” function in heavy grass cutting conditions

(cutting of dense, high, humid grass).

 5.6  CUTTING HEIGHT ADJUSTMENT

Lower or raise the chassis to cut the

grass at different heights.

   Carry out this operation when the cutting means

is stationary.

•

To adjust the cutting height, press the button (Fig.8.A)

and lift or lower the chassis using the hand grip

(Fig.8.B), until the desired position is reached.

6.  USING THE MACHINE

  The safety regulations to follow are described in

chap. 2. Strictly comply with these instructions to avoid

serious risks or dangers.

 6.1  PRELIMINARY PROCEDURES

Before starting work , it is necessary to carry out

several checks and operations to ensure you

can work efficiently and in maximum safety:

Make sure that the safety key is not inserted in its slot.

Place the machine in a stable horizontal

position on the ground.

 6.1.1  Checking the battery

Before using the machine for the first time after

purchase, fully charge the battery following

the instructions in the battery booklet.

Before every use of the machine, check the battery charge

status according to the instructions in the battery booklet.

 6.1.2

Preparing the machine before starting work

 NOTE

 This machine can be used to mow

lawns in various ways; before starting, prepare the

machine based on how the lawn is to be mowed.

a.

Preparation for grass cutting and

collection in the grass catcher:

1.

For models with side discharge option: make sure

that the side discharge guard (Fig. 9.A) is low

-

ered and locked with the safety lever (Fig. 9.B).

2.

Insert the grass catcher as indicated in the figure

(Fig.9.C). Place the side pins in the guides at the

base of the handle, (Fig.9.D) and push the catcher

forward until you hear a "click" sound (Fig.9.E).

b.

Preparation for grass cutting and rear

grass discharge on the ground:

1.

Remove the grass catcher.

2.

Lift the rear discharge guard (Fig.10.A) and

hook the rear discharge chute (Fig.10.B) in the

provided holes, checking that it is stable

.

3.

For models with side discharge option: make sure

that the side discharge guard (Fig. 10.C) is low

-

ered and locked with the safety lever (Fig. 10.D).

To remove the rear discharge chute:

1.

Lift the rear discharge guard (Fig.10.A).

2.

Lift the rear discharge chute, releas

-

ing it from the holes (Fig.10.B).

c.

Preparation for grass mowing and

chopping (mulching function):

1.

Lift the rear discharge guard (Fig.11.A) and insert

the chute plug (Fig.11.B) in the discharge opening.

2.

For models with side discharge option: make sure

that the side discharge guard (Fig. 10.C) is low

-

ered and locked with the safety lever (Fig. 10.D).

To remove the chute plug:

1.

Lift the rear discharge guard (Fig.11.A).

2.

Remove the chute plug (Fig.11.B).

d.

Preparation for grass cutting and

side discharge on the ground:

1.

Lift the rear discharge guard (Fig.12.A) and insert

the chute plug (Fig.12.B) in the discharge opening.

2.

Slightly push the safety lever (Fig.12.C) and

lift the side discharge guard (Fig.12.D).

3.

Insert the side discharge chute (Fig.12.E).

4.

Close the side discharge guard (Fig.12.D) so as

to lock the side discharge chute (Fig.12.E).

To remove the side discharge chute:

1.

Slightly push the safety lever (Fig.12.C) and

lift the side discharge guard (Fig.12.D).

2.

Release the side discharge chute (Fig.12.E)

To remove the chute plug:
