12

8-3 OPERATION PROCEDURES

During operation, tightly hold the stop control handle with
both hands.

Note:

During operation, when the stop control

handle is released, the engine will stop and thus stopping
the lawn mower from operating.

WARNING!

 In order to avoid any unintentional

start-ups of the lawn mower, it comes equipped with an
engine brake which must be pulled back before the
engine can be started. When the engine control lever is
released it must return to its initial position, at which point
the engine automatically switches off.

Note:

 Engine brake (brake handle): Use the lever

to stop the engine. When you release the lever the engine
and the blade stop automatically. To mow, hold the lever in
the working position. Before you start to mow, check the
start/stop lever several times to be sure that it is working
properly. Ensure that the tension cable can be smoothly
operated (i.e. is not catching or kinking in any way).

8-4 TO STOP ENGINE

CAUTION:

The blade continues to rotate for a

few seconds after the engine is shut off.
1. Release the stop control handle to stop the engine

and blade.

2. Disconnect and ground the spark plug wire as

instructed in the separate engine manual to prevent
accidental starting while equipment is unattended.

8-5 CONNECTION FOR AUTO MOVE

The mower is equipped with a speed adjusting system
which can adjust 3 speeds from 3.0 km/h to 4.5 km/h.
Position

: the slowest position; Position

: the

fastest position
The step as below:
1. Release the Self-drive control handle until the lawn

mower doesn’t go forward.

2. Adjust the appropriate speed which you want.

(Fig. 22)

3. Grasp the Self-drive control handle to go on mowing.

CAUTION:

Your mower is designed to cut normal

residential grass of a height no more than 250 mm.
Do not attempt to mow through unusually tall dry or wet
grass (e.g., pasture) or piles of dry leaves. Debris may
build up on the mower deck or contact the engine exhaust
presenting a potential fire hazard.

8-6 FOR THE BEST RESULTS WHEN

MOWING

Clear lawn of debris. Be sure that the lawn is clear of
stones, sticks, wire or other foreign objects which could be
accidentally thrown out by the mower in any direction and
cause serious personal injury to the operator and others
as well as damage to property and surrounding objects.

Do not cut wet grass. For effective mowing do not cut wet
grass because it tends to stick to the underside of the
deck preventing proper mowing of the grass clippings. Cut
no more than 1/3 the length of the grass. The
recommended cut for mowing is 1/3 the length of the
grass. Ground speed will need to be adjusted so the
clippings can be dispersed evenly into the lawn. For
especially heavy cutting in thick grass it may be
necessary to use one of the slowest speeds in order to get
a clean well mowed cut. When mowing long grass you
may have to cut the lawn in two passes, lowering the
blade another 1/3 of the length for the second cut and
perhaps cutting in a different pattern than was used the
first time. Overlapping the cut a little on each pass will
also help to clean up any stray clippings left on the lawn.
The mower should always be operated at full throttle to
get the best cut and allow it to do the most effective job of
mowing. Clean underside of deck. Be certain to clean the
underside of the cutting deck after each use to avoid a
build-up of grass, which would prevent proper mulching.
Mowing leaves. The mowing of leaves can also be
beneficial to your lawn. When mowing leaves make sure
they are dry and are not laying too thick on the lawn. Do
not wait for all the leaves to be off the trees before you
mow.

WARNING:

 If you strike a foreign object, stop the

engine. Remove wire from spark plug, thoroughly inspect
the mower for any damage and repair the damage before
restarting and operating the mower. Extensive vibration of
the mower during operation is an indication of damage.
The unit should be promptly inspected and repaired.

8-7 GRASS CATCHER

Empty and clean the bag, make sure it is clean and
ensure its meshwork is ventilated.

(Fig. 23)

8-8 DECK

The underside of the mower deck should be cleaned after
each use to prevent a buildup of grass clippings, leaves,
dirt or other matter. If this debris is allowed to accumulate,
it will invite rust and corrosion, and may prevent proper
mulching. The deck may be cleaned by tilting the mower
and scraping clean with a suitable tool (make certain the
spark plug wire is disconnected).

8-9 HEIGHT ADJUSTMENT

INSTRUCTIONS

CAUTION:

Do not at any time make any

adjustment to lawn mower without first stopping the
engine and disconnecting the spark plug wire.

CAUTION:

Before changing mowing height, stop

mower and disconnect spark plug cable.
Your mower is equipped with a central height adjustment
lever offering 5 height positions. (25 mm – 70 mm)
1. Stop mower and disconnect spark plug cable before

changing mower cutting height.

2. The central height adjustment lever offers you

5 different height positions.

(Fig. 24)
