4. TECHNICAL DATA
5. ASSEMBLY
5-1 ASSEMBLY THE FOLDING HANDLE
A) Fix the lower handlebars into the unit body with
locking knobs as shown.
(Fig. 2, Fig. 3, Fig. 4, Fig. 5)
B) Release the upper handlebars for folding. Connect the
upper handle and the lower handle with the locking
knob.
(Fig. 6, Fig. 7)
C) Position all cables over the handle shafts. Clamp them
around the middle of lower handles by the cable
clamps so that the cables are fixed on the outside of
the machine. Otherwise the cables may be pinched by
opening/closing the rear cover or forced by folding the
upper handle.
(Fig. 8)
5-2 ASSEMBLY THE GRASS CATCHER
1. To fit: Lift the rear cover and hang the grass catcher on
the shaft of rear of mower.
(Fig. 9, Fig. 10)
2. To remove: Grasp and lift the rear cover, remove grass
catcher.
5-3 STARTER HANDLE
Move the starter handle from the engine to the rope guide.
(Fig. 11, Fig. 12)
5-4 HEIGHT OF CUT
Apply outward pressure to disengage lever from rack.
Move lever forward or back to adjust height.
(Fig. 13 and
see clause 8-9)
6. ADJUSTMENT FOR AN
APPROPRIATE HANDLE
HEIGHT
1) Back out the locking knob which fixed the lower
handle, refer to
Fig. 14
.
2) Refer to
Fig. 15
, move the lower handle up and down,
adjust it to the proper height.
There is 3 adjusting height to be choose on this type
lawn mower; at 1 height, lower handle to the ground is
highest., 3 height is the lowest.
3) Adjusting to the proper height, then fix the lower
handle by the locking knobs.
WARNING:
The left side and right side of lower
handle must adjust to the same height.
7. “3 in 1”
This lawn mower can be retrofitted from its normal
function, based on the application purpose:
From rear-discharge mower to:
1. Mulching mower or
2. Side-discharge mower.
Model
PLM5113N
Engine type
B&S 675EX series, ReadyStart
Self Propel
Yes
Engine Displacement
190 cm
3
Nominal Power
2.5 kW
Blade Width
510 mm
Idle Speed
2,800/min
Fuel Tank Capacity
1.0L
Oil tank capacity
0.6L
Grass catch bag capacity
65L
Net Weight
37.7 kg
Height adjustment
25 – 70 mm, 5 adjustment
Guaranteed sound power level at the operator’s position
(According to EN ISO 5395-1 Annex F & EN ISO 5395-2,
EN ISO 4871)
86.6 dB (A)
(K = 3 dB (A))
Measured sound power level
94.9 dB (A)
(K = 1.78 dB (A))
Guaranteed sound power level
(According to 2000/14/EC)
98 dB (A)
Vibration
(According to EN ISO 5395-1 Annex G & EN ISO 5395-2)
4.17 m/s
2
(K = 1.5 m/s
2
)
