 English |

17

Bosch Power Tools

1 619 929 J79 | (23.11.11)

Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:

Sound pressure level 89 dB(A); Sound power level

100 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

a

h

= 5.5 m/s

2

, K = 2.5 m/s

2

.

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

sure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

riod.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents: EN 60745

according to the provisions of the directives 2011/65/EU,

2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:

Robert Bosch GmbH, PT/ETM9,

D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

26.10.2011

Assembly

Inserting a Router Bit (see figure A)

f

Before any work on the machine itself, pull the mains

plug.

f

It is recommended to wear protective gloves when in-

serting or replacing router bits.

Depending on the application, router bits are available in the

most different designs and qualities.

Router bits made of high speed steel (HSS)

 are suitable for

the machining of soft materials, e. g. softwood and plastic.

Carbide tipped router bits (HM)

 are particularly suitable for

hard and abrasive materials, e. g. hardwood and aluminium.
Original router bits from the extensive Bosch accessories pro-

gram are available at your specialist shop.
Only use clean router bits that are in perfect condition.
– Fold the chip shield

6

 down.

– Push the spindle lock lever

4

 in clockwise direction and

hold it in this position (

n

). If required, turn the motor spin-

dle by hand until it is locked.

– Loosen the tightening nut

23

 with the open-end spanner

25

 (size 24 mm) by turning in antclockwise direction (

o

).

– Insert the router bit into the collet. The shank of the router

bit must be immersed at least 20 mm into the collet.

– Tighten the tightening nut

23

 with the open-end spanner

25

 (size 24 mm) by turning in clockwise direction. Release

the spindle lock lever

4

.

– Fold the chip shield

6

 up again.

f

Do not insert a router bit with a diameter larger than

50 mm when the guide bushing is not mounted.

Such

router bits do not fit through the base plate.

f

Do not tighten the tightening nut of the collet without a

router bit inserted.

Otherwise the collet can be damaged.

Dust/Chip Extraction (see figure B)

f

Dusts from materials such as lead-containing coatings,

some wood types, minerals and metal can be harmful to

one’s health. Touching or breathing-in the dusts can cause

allergic reactions and/or lead to respiratory infections of

the user or bystanders.

Certain dusts, such as oak or beech dust, are considered

as carcinogenic, especially in connection with wood-treat-

ment additives (chromate, wood preservative). Materials

containing asbestos may only be worked by specialists.

– As far as possible, use a dust extraction system suita-

ble for the material.

– Provide for good ventilation of the working place.

– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the

materials to be worked.

f

Prevent dust accumulation at the workplace.

Dusts can

easily ignite.

Mounting the Extraction Adapter

The extraction adapter

27

 can be mounted with the hose con-

nection to the front or to the rear. When the guide bushing

adapter

44

 is mounted, it is possible that the guide bushing

adapter must be turned by 180 °  so that the extraction adapt-

er

27

 does not touch the release lever

46

. When mounting

with the hose connection in front, the chip shield

6

 must be

removed first. Fasten the extraction adapter

27

 with the

2 knurled screws

28

 to the base plate

12

.

Connecting the Dust Extraction

Insert an extraction hose (Ø 35 mm)

26

 (accessory) into the

mounted extraction adapter. Connect the extraction hose

26

to a vacuum cleaner (accessory).

Dr. Egbert Schneider

Senior Vice President

Engineering

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI
