16
| English
1 619 929 J79 | (23.11.11)
Bosch Power Tools
Intended Use
The machine is intended for routing grooves, edges, profiles
and elongated holes as well as for copy routing in wood, plas-
tic and light building materials, while resting firmly on the
workpiece.
With reduced speed and with appropriate routing bits, non-
ferrous alloys can also be machined.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1
Right handle (insulated gripping surface)
2
Lock-on button for On/Off switch
3
Thumbwheel for speed preselection
4
Spindle lock lever
5
Wing bolt for guide rods of parallel guide (2x) *
6
Chip shield
7
Router bit *
8
Seat for parallel guide rods
9
Guide plate
10
Step buffer
11
Adjusting screws for step buffer
12
Base plate
13
Dust boot
14
Wing bolt for depth stop adjustment
15
Depth stop
16
Slide with index mark
17
Left handle (insulated gripping surface)
18
Scale for depth-of-cut
19
Scale for depth-of-cut fine adjustment
20
Adjustment knob for depth-of-cut fine adjustment
21
Mark for zeroing
22
Release lever
23
Tightening nut with collet
24
On/Off switch
25
Open-end spanner, size 24 mm *
26
Extraction hose (Ø 35 mm) *
27
Extraction adapter *
28
Knurled screw for extraction adapter (2x) *
29
Parallel guide *
30
Guide rod for parallel guide (2x) *
31
Wing bolt for fine adjustment of parallel guide (2x) *
32
Wing bolt for coarse adjustment of
parallel guide (2x) *
33
Fine-adjustment knob for parallel guide*
34
Adjustable edge guide for parallel guide *
35
Extraction adapter for parallel guide *
36
Router compass/guide-rail adapter *
37
Router compass handle *
38
Wing bolt for coarse adjustment of
router compass (2x) *
39
Wing bolt for fine adjustment of
router compass (1x) *
40
Fine-adjustment knob for router compass *
41
Centring screw for compass stop *
42
Base spacer
(included in the “router compass” set) *
43
Guide rail *
44
SDS guide-bushing adapter
45
Fastening screw for guide bushing adapter (2x)
46
Release lever for guide bushing adapter
47
Guide bushing
48
Pan head screw for guide plate
49
Countersunk head screw for guide plate
50
Centring pin
* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Plunge router
GOF 900 CE
Professional
GOF 1300 CE
Professional
Article number
0 601 614 6..
0 601 613 6..
Rated power input
W
900
1 300
No-load speed
min
-1
12 000 – 24 000
12 000 – 24 000
Speed preselection
z
z
Constant electronic control
z
z
Connection for dust extraction
z
z
Tool holder
mm
inch
6 – 8
¼
6 – 12.7
¼ – ½
Plunge depth
mm
50
58
Weight according to EPTA-Procedure 01/2003
kg
3.5
4.8
Protection class
/
II
/
II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
OBJ_BUCH-203-004.book Page 16 Wednesday, November 23, 2011 9:50 AM
