Relay box  Receives documents, then relays them to other machines. The
machine that relays the document is called a  hub . Your fax machine can either
send to a hub or it can be a hub.

4 elements of an F-Code box

Each F-Code box has the following four elements:
(1) F-Code box number (01-50)
(2) F-Code box name (up to 16 characters)
(3) F-Code sub-address (up to 20 characters - can include numbers and the * and #

characters only)

(4)

I

.

D

. Code (4 digits)

You will choose the information for each of these elements, and enter it into your
machine. The following steps will walk you through entering and changing that
information.

To create or modify an F-Code box:

1

Keep pen and paper with you as you follow these steps. As you decide on a
sub-address and enter it into your machine, write it down. Remember to:
(1) write down which box goes with which sub-address, (2) write down any
passwords or

I

.

D

. codes you enter, (3) keep these printed records in a safe

place.

2

Press Program key,

C

, 4, 0, 1,

ENTER

. Depending on whether you already

have a name entered for F-Code box 01, the

LCD

shows:

or

3

Use the numeric keypad to enter the two-digit number (01-50) of the F-Code
box you want to create or modify. Here, we ve entered 0, 3 and see either:

or

4

If want to select a different F-Code box than the one that appears on the

LCD

,

use the numeric keypad to enter the two-digit F-Code box number now.

5

Press

ENTER

. What you do next depends on whether you re creating or

modifying the F-Code box:
If creating   skip to step 7.
If modifying   the

LCD

asks you to enter the proper

I

.

D

. code. The

LCD

shows:

6

Use the numeric keypad to enter the 4-digit

I

.

D

. code (not the

ITU

-

T

sub-

address and not the

ITU

-

T

password) and then press

ENTER

.

Note: If you enter an invalid

I

.

D

. code, the fax machine rejects the attempt

and aborts this operation.

7

The machine is now asking you to name this F-Code box. The

LCD

shows:

or

If you do not want to enter or change this F-Code box s name, skip to step 9.
If you do want to enter or change this F-Code box s name, go on to step 8.

8

Enter the name by using the one-touch keys. (If necessary, review  Entering
characters , page 1.12) An F-Code box s name can be up to 16 characters in
length.

9

Press

ENTER

to save the box s name and continue. The

LCD

shows:

or

The fax machine now asks for this F-Code box s sub-address. This is the
numerical identifier you must enter in order to communicate with any remote
F-Code compatible fax.

If you do not want to change an existing sub-address, skip to step 11.

10

Use the numeric keypad to enter the sub-address to identify this F-Code box.
The sub-address can be up to 20 characters in length and include any
combination of numbers and the * and # characters (but no other non-
numeric characters).

Note: No other F-Code box in this machine can have the same sub-address

as the one you enter here.

11

Press

ENTER

to save the sub-address.

Note: If you entered a sub-address already being used by another F-Code

box, the machine beeps and briefly displays:

The machine now returns you to step 10. Please enter a different
number for your F-Code box s sub-address.

03:Sub-Address No.
Sub-Address In Use

03:Sub-Address No.
654321_

03:Sub-Address No.
123456_

03:Sub-Address No.
_

03:Box Name;Upper
Muratec America_

03:Box Name;Upper

_

03:Set F-Code Box
Enter I.D. Code:****

Select F-Code Box
03:Muratec America

Select F-Code Box
03:No Number Stored

Select F-Code Box
01:NY Branch Office

Select F-Code Box
01:No Number Stored

Advanced features

3.27
