• RESIDUAL HEAT INDICATOR

The control panel tells the user when the surface temperature of
the cooking zones exceeds about 60°C, by the following displaying:
    . When the temperature goes back below 60°C, the      display
goes off.

For ending the cooking, we advise switching off the cooking zone
and using the residual heat of the zone to finish cooking gently.

N.B. After a cut in the current, the residual heat indicator disappears
completely, even if the surface temperature exceeds 60°C.

• OPERATING THE ADDITIONAL COOKING ZONE
  (TWO ZONES)

The cooking zone with two zones is fitted certain models. It can
be either concentric or extendable.

It is active in totality when the cooking zone is in function ;
the control led of the additional cooking is displayed.
To desactivate the additional cooking zone :

- Press on the additional cooking zone button     . The corresponding

control led for the additional cooking zone goes off when it is
desactivated.

To re-activate the additional cooking zone :

- Press on the additional cooking zone button     . The corresponding

control led for the additional cooking zone is active.

• O P E R AT I N G   T H E   A D D I T I O N A L   C O O K I N G   Z O N E

(THREE ZONES)

T h e   a d d i t i o n a l   c o o k i n g   z o n e   i s   f i t t e d   o n l y   o n e   m o d e l .

It is active in totality when the cooking zone is in function ;
the two control leds of the additional cooking are displayed.
To desactivate the additional cooking zones :

- Press one time the additional cooking zone button    . The

corresponding control led for the external additional cooking
zone goes off when it is desactivated.

- Press two times the additional cooking zone button    . The

corresponding control led for the central additional cooking zone
goes off when it is desactivated.

To re-activate the additional cooking zones :

- Press on the additional cooking zone button, one or two times

on the additional cooking zone button, according to the need.

• PROGRAMMING A COOKING ZONE (according to the model)

Every cooking zone can be programmed for a maximum time of
99 minutes.
- Start the required zone by following the previous instructions.

The control LED near the heat level must be displayed, it shows
that the zone is live.

- Press the Timer button.

The zone mark around the timer display shows the controlled
zone.

- Press again on the timer button to select a time in minutes

between 0 and 99 minutes or press on the "-" button to decrease
the time between 60 minutes and 0.

the programmed time can be modified at any moment reactivating

the cooking zone and then the timer button.

When the time is run, the cooking zone goes off automatically
and an audible beep sounds for 1 minute, press the timer button
to stop it.

the time can be used alone as reminder, it will ring at the end of
the programmed time.

The locking function prevents the children from starting the hob.
It is also used for cleaning the control strip as the controls can be
locked without the hob being on.

To lock the hob :

- Press the on/off button     .
- Press simultaneously "

-

 " button and "

+

 " button of the front

right zone (CH 633 front left zone), and then press again on
the "

+

 " button of this zone. The hob is locked, the locking

indicator "

L

 " is displayed on all zones for 20 seconds.

To unlock the hob :

- Press the on/off button      . The locking indicator "

L

 " is displayed

on all zones.

- Press simultaneously the "

-

 " button and the "

+

 " button of the

front right zone (CH 633 front left zone), and then press again
on the "

 -

 " button of this zone.

The hob is unlocked.

• LOCKING BUTTON OPERATION

• FAST HEATER OPERATION

Starting the fast heater

- Press the on/off button     .
- Start the required zone, press the "

+

 " button to obtain position

“

9

”, release the button briefly and press again the "

+

 " button ;

the display alternates showing "

A

" “fast heater” and "

9

" heat

level.

- If necessary reduce to the required heat position, the display

alternates showing "A" “fast heater” and the new heat position.

Cooking

position

Power

released

(%)

Time of

fast heater

(minutes)

Maximum

operating

time before

automatic

cut off*

0

:

0 %

:

0

:

0 H

1

:

3 %

:

1

:

6 H

2

:

6 %

:

3

:

6 H

3

:

11 %

:

5

:

5 H

4

:

16 %

:

6,5

:

5 H

5

:

19 %

:

8,5

:

4 H

6

:

32 %

:

2,5

:

1,5 H

7

:

45 %

:

3,5

:

1,5 H

8

:

65 %

:

4,5

:

1,5 H

9

:

100 %

:

0

:

1,5 H

E.g. 1800 W zone at position 6 = 32% of 1800 W power released

When the “Fast heater” is on, the zone supplies 1800 W power
f o r   2 . 5   m i n u t e s ,   a n d   a d j u s ts   t o   5 7 6   W   a ft e r   t h i s   t i m e .

* For increased safety, the cooking zones cut off automatically if
they are left on too long. The cut off depends on the heat level
used.

To desactivate the fast heater

- Switch on the cooking zone, press the "

-

 " button to come back

to a normal heat level, decrease to the heat level required or to
" 0 " to stop the cooking zone.

• Before carrying out any maintenance work on the hob, allow it

to cool down.

• Only products, (creams and scrapers) specifically designed for

glass ceramic surfaces should be used. They are obtainable
from hardware stores.

• Avoid spillages, as anything which falls on to the hob surface

w i l l   q u i c k l y   b u r n   a n d   w i l l   m a k e   c l e a n i n g   m o r e   d i f f i c u l t .

• It is advisable to keep away from the hob all substances which

are liable to melt, such as plastic items, sugar, or sugar-based
products.

MAINTENANCE:

- Place a few drops of the specialised cleaning product on the

hob surface.

- Rub any stubborn stains with a soft cloth or with slightly damp

kitchen paper.

- Wipe with a soft cloth or dry kitchen paper until the surface is

clean.

  8. CLEANING AND MAINTENANCE

9 GB-IE

• GENERAL STOP

The cooking zones and the timer can be stopped at any
moment by pressing the On-Off button.
