12

English

NOTE

Standard Idle rpm is 2500 – 3000 rpm.

WARNING

When the engine is idling the cutting attachment must under no
circumstances rotate.

Air

 fi

lter

 (

Fig.

28

)

The air

fi

 lter must be cleaned from dust and dir t in order to avoid:

○

 Carburetor

malfunctions

○

 Star ting

problems

○

  Engine power reduction

○

  Unnecessar y wear on the engine par ts

○

  Abnormal fuel consumption

Clean the air

fi

 lter daily or more often if working in exceptionally

dusty areas.

Cleaning

the

air

 fi

lter

Remove the air

fi

 lter cover and the

fi

 lter (24). Rinse it in warm soap

suds. Check that the

fi

 lter is dr y before reassembly. An air

fi

 lter

that has been used for some time cannot be cleaned completely.
Therefore, it must regularly be replaced with a new one. A damaged

fi

 lter must always be replaced.

Fuel

 fi

lter

 (

Fig.

29

)

Drain all fuel from fuel tank and pull fuel

fi

 lter line from tank. Pull

fi

 lter element out of holder assembly and rinse element in warm

water with detergent.
Rinse thoroughly until all traces of detergent are eliminated.
Squeeze, do not wring, away excess water and allow element to air
dr y.

NOTE

If element is hard due to excessive dir t buildup, replace it.

Spark

plug

 (

Fig.

30

)

The spark plug condition is in

fl

 uenced by:

○

  An incorrect carburetor setting

○

  Wrong fuel mixture (too much oil in the gasoline)

○

  A dir ty air

fi

 lter

○

  Hard running conditions (such as cold weather)

These factors cause deposits on the spark plug electrodes, which
may result in malfunction and star ting di

ffi

  culties. If the engine

is  low  on  power,  di

ffi

  cult  to  star t  or  runs  poorly  at  idling  speed,

always check the spark plug

fi

 rst. If the spark plug is dir ty, clean it

and check the electrode gap. Re-adjust if necessar y. The correct
gap is 0.6 mm. The spark plug should be replaced after about 100
operation hours or earlier if the electrodes are badly eroded.

Mu

ffl

er

 (

Fig.

31

)

Remove the mu

ffl

  er and clean out any excess carbon from the

exhaust por t or mu

ffl

  er inlet ever y 100 hours of operation.

Cylinder

 (

Engine

cooling

) (

Fig.

32

)

The engine is air cooled, and air must circulate freely around engine
and over cooling

fi

 ns on cylinder head to prevent overheating.

Ever y 100 operating hours, or once a year (more often if conditions
require), clean

fi

 ns and external sur faces of engine of dust, dir t and

oil deposits which can contribute to improper cooling.

NOTE

Do not operate engine with engine shroud or mu

ffl

  er  guard

removed as this will cause overheating and engine damage.

Angle

transmission

 (

Fig.

33

)

Check angle transmission or angle gear for grease level about ever y
50 hours of operation by removing the grease

fi

 ller plug on the side

of angle transmission.
If  no  grease  can  be  seen  on  the

fl

 anks of the gears,

fi

 ll  the

transmission with quality lithium based multipurpose grease up to
3/4. Do not completely

fi

 ll the transmission.

Blade

WARNING

  Wear protective gloves when handling or per forming

maintenance on the blade. (

Fig.

34

)

○

  Use a sharp blade. A dull blade is more likely to snag and thrust.

Replace the fastening nut if it is damaged and hard to tighten.

○

  When replacing blade, purchase one recommended by Hitachi,

with a 25.4 mm (one inch)

fi

 tting hole.

○

  When installing a saw blade, always face the stamped side up.

In the case of a 3 tooth blade, it can be used on either side.

○

  Use the correct blade for the type of work.

○

  When replacing blades, use appropriate tools.

○

  When cutting edges become dull, re-sharpen or

fi

 le as shown

in the illustration. Incorrect sharpening may cause excessive
vibration.

○

  Discard blades that are bent, warped, cracked, broken or

damaged in any way.

NOTE

When  sharpening  blade  it  is  impor tant  to  maintain  an  original
shape of radius at the base of the tooth to avoid cracking.

Nylon

head

Nylon line replacement

○

  Remove the cutting body cap by pushing inward the locking

tabs on  the side of the nylon head (

Fig.

35

). Take out the spool

(

Fig.

36

), hook the new nylon line into the hole of the spool, then

wind it around the spool (

Fig.

37

).

When the nylon line has been wound around the spool,
temporarily fasten it in the opening of the spool at about 10 cm
from the end. (

Fig.

38

) Then thread the nylon line through the

hole on the side of the nylon head and place the cutting body
cap in reverse order of the cap removal. Pull the right and left
nylon lines until they are secured about 15

–

 16 cm from the end.

(

Fig.

40

)

NOTE

○

  The nylon head is designed for nylon lines with an outer

diameter of 2.5 mm. Do not use nylon lines with a di

ff

 erent outer

diameter.

○

  Make sure that the right and left nylon lines are of equal length

since vibrations will other wise increase.

Maintenance

schedule

Below you will

fi

 nd some general maintenance instructions. For

fur ther information please contact your Hitachi dealer.

Daily

maintenance

○

  Clean the exterior of the unit.

○

  Check that the harness is undamaged.

○

  Check the blade guard for damage or cracks. Change the guard

in case of impacts or cracks.

○

  Check that the cutting attachment is properly centred, sharp,

and without cracks. An o

ff

 -centre cutting attachment induces

heav y vibrations that may damage the unit.

○

  Check that the cutting attachment nut is su

ffi

  ciently tightened.

○

  Make sure that the blade transpor t guard is undamaged and

that it can be securely

fi

 tted.

○

  Check that nuts and screws are su

ffi

  ciently tightened.

Weekly

maintenance

○

  Check the star ter, especially the cord and return spring.

○

  Clean the exterior of the spark plug.

○

  Remove it and check the electrode gap. Adjust it to 0.6 mm, or

change the spark plug.

○

  Clean the cooling

fi

 ns on the cylinder and check that the air

intake at the star ter is not clogged.

○

  Check that the angle gear is

fi

 lled with grease up to 3/4.

○

  Clean the air

fi

 lter.

Monthly

maintenance

○

  Rinse the fuel tank with gasoline.

○

  Clean the exterior of the carburetor and the space around it.

○

  Clean the fan and the space around it.
