11

English

○

  Always move the brush cutter at least 3 m from the fueling area

before star ting.

○

  Always  wash  any  spilled  fuel  from  clothing  immediately  with

soap.

○

  Be sure to check for any fuel leakage after refueling.

Before  fueling,  clean  the  tank  cap  area  carefully,  to  ensure  that
no dir t falls into the tank. Make sure that the fuel is well mixed by
shaking the container, before fueling.

Starting

 (

Fig.

16

)

CAUTION

Before star ting, make sure the cutting attachment does not
touch any thing.

1.  Slide ignition switch (13) to RUN position. (

Fig.

16

)

*  Push priming bulb (16) several times so that fuel

fl

 ows through

return pipe. (

Fig.

17

)

2.  With the safety trigger (14) (if so equipped) pressed, pull

throttle trigger and push throttle lock (15). Then slowly release
the throttle trigger

fi

 rst, then the safety trigger. This will lock the

throttle in star ting position.

3.  Set choke lever to CLOSED position (17). (

Fig.

18

)

4.  Pull recoil star ter briskly, taking care to keep the handle in your

grasp and not allowing it to snap back. (

Fig.

19

)

5.  When you hear the engine want to star t, return choke lever to

RUN position (open). Then pull recoil star ter briskly again.

NOTE

If engine does not star t, repeat procedures from 2 to 5.

6.  After star ting engine, pull throttle trigger to release throttle lock.

Then allow the engine about 2– 3 minutes to warm up before
subjecting it to any load.

Cutting

 (

Fig.

20,

21,

22

)

○

  When cutting, operate engine at over 6500 rpm. Extended time

of use at low rpm may wear out the clutch prematurely.

○

  Cut grass from right to left.

○

  Blade thrust may occur when the spinning blade contacts a

solid object in the critical area.

A dangerous reaction may occur causing the entire unit and
operator to be thrust violently. This reaction is called blade
thrust. As a result, the operator may lose control of the unit
which may cause serious or fatal injur y. Blade thrust is more
likely to occur in areas where it is di

ffi

  cult to see the material to

be cut.

○

  Wear the harness as shown in the

fi

 gure. The blade turns

counter-clockwise, therefore, be advised to operate the unit
from right to left for e

ffi

  cient cutting. Keep onlookers out of

working area at least 15 m.

NOTE

Press the quick release button or pull emergency release

fl

 ap in

the event of emergency.

(

Fig.

23

)

How

to

use

the

shoulder

harness

Wear the shoulder harness on your shoulder as shown

Fig.

21

and hook it on the hanger of the machine. Adjust the length of the
shoulder harness to the most comfor table position. (

Fig.

21

)

To remove the machine from the shoulder harness, hold the main
pipe of the machine

fi

 rmly by one hand and then remove the hook

(19) of the shoulder harness from the hanger (20). (

Fig.

23-a

)

How

to

reinstall

the

hook

after

using

the

emergency

release

pinch

It needs to go through the buckle (21) of the hook (19) to the metal
plate (22) on the harness and go through the plate (23) of the
emergency release pinch to the metal plate (22) on the harness.
(

Fig.

23-b

)

After installing the buckle onto the harness, pull the hook (19) and
make sure the hook (19) is securely

fi

 xed on the harness, then hook

it to the hanger (20). (

Fig.

23-a

)

WARNING

○

  When using the machine, wear the shoulder harness and hold

the machine correctly with both hands.

If you feel that there is something dangerous, separate the
brush cutter from your body by pulling the emergency release
pinch (18) of the harness to the direction of the arrow shown in

Fig.

23-a

.

○

  If the cutting attachment should strike stones or other debris,

stop the engine and make sure that the attachment and related
par ts are undamaged. When grass or vines wrap around
attachment, stop engine and attachment and remove them.

NOTE

If you pull the emergency release pinch without holding the
machine, the machine will fall to your feet. Pull the emergency
release pinch while holding the main pipe of the machine by
one hand.

Before operation, make sure that the emergency release pinch
on the shoulder harness is working properly.

Stopping

 (

Fig.

24

)

Decrease engine speed and run at an idle for a few minutes, then
turn o

ff

   ignition switch (13).

WARNING

A cutting attachment can injure while it continues to spin after
the engine is stopped or power control is released. When the
unit is turned o

ff

 , make sure the cutting attachment has stopped

before the unit is set down.

How

to

use

nylon

head

When cutting, operate engine at over 6500 rpm. Extended use at
low rpm may wear out the clutch prematurely.
This  product  is  designed  so  that  it  will  stop  cutting  when  the  nylon
line becomes 16 cm or longer.

WARNING

A cutting attachment can injure while it continues to spin after the
engine is stopped or power control is released. When the unit is
turned o

ff

 , make sure the cutting attachment has stopped before

the unit is set down.

Set the engine speed as low as possible and tap the Head on the
ground. (

Fig.

25

) Also, you can extend nylon line with hands but the

engine must be completely stopped. (

Fig.

26

)

Adjust nylon line to proper length 11

–

 14 cm before each operation.

MAINTENANCE

MAINTENANCE, REPL ACEMENT OR REPAIR OF THE EMISSION
CONTROL DEVICES AND SYSTEMS MAY BE PERFORMED
BY ANY NON-ROAD ENGINE REPAIR ESTABLISHMENT OR
INDIVIDUAL.

Carburetor

adjustment

 (

Fig.

27

)

WARNING

○

  The cutting attachment may be spinning during carburetor

adjustments.

○

  Never star t the engine without the complete clutch cover and

tube assembled! Other wise the clutch can come loose and
cause personal injuries.

In the carburetor, fuel is mixed with air. When the engine is test
run at the factor y, the carburetor is basically adjusted. A fur ther
adjustment may be required, according to climate and altitude. The
carburetor has one adjustment possibility:

T

=

Idle

speed

adjustment

screw.

Idle

speed

adjustment

 (

T

)

Check that the air

fi

 lter is clean. When the idle speed is correct, the

cutting attachment will not rotate. If adjustment is required, close
(clockwise) the T-screw, with the engine running, until the cutting
attachment star ts to rotate. Open (counter-clockwise) the screw
until the cutting attachment stops. You have reached the correct idle
speed when the engine runs smoothly in all positions well below the
rpm when the cutting attachment star ts to rotate.
If the cutting attachment still rotates after idle speed adjustment,
contact your Hitachi dealer.
