9

ENG

ENGLISH

9

EXTERNAL CONTROL DEVICE SETUP

1 0 0

5th Band

0 0 1 0

1

20(decimal)

Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x]

* It depends on model, and can  adjust when sound

mode is EQ adjustable value.

19. Energy Saving (Command: j q)

►

To reduce the power consumption of the TV. You

can also adjust Energy Saving in PICTURE menu.

Transmission [j][q][ ][Set ID][ ][Data][Cr]

Data

  00 : Off

  01 : Minimum

  02 : Medium

  03 : Maximum

  04 :  Auto (For LCD TV / LED TV) /

Intelligent sensor (For PDP TV)

  05 : Screen off
*  (Depending on model)

Ack [q][ ][Set ID][ ][OK/NG][Data][x]

20. Tune Command (Command: m a)

*  This command may work differently depending on

model and signal.

•

For Europe, Mid-East, Colombia, Asia except

South Korea and Japan Model

►

Select channel to following physical number.

Transmission [m][a][ ][Set ID][ ][Data 00][ ]
[Data 01][ ][Data 02][Cr]

*  Analog Antenna/Cable

[Data 00][Data 01] Channel Data

Data  00  :  High byte channel data

Data  01  :  Low byte channel data

  - 00 00 ~ 00 C7 (Decimal : 0 ~ 199)

Data 02 : Input Source (Analog)

  - 00 : Antenna TV (ATV)

  - 80 : Cable TV (CATV)
*  Digital Antenna/Cable/Satellite

[Data 00][Data 01]: Channel Data

Data  00 : High Channel data

Data  01 : Low Channel data

  - 00 00 ~ 27 0F (Decimal: 0 ~ 9999)

Data  02 : Input Source (Digital)

  - 10 : Antenna TV (DTV)

  - 20 : Antenna Radio (Radio)

  - 40 : Satellite TV (SDTV)

  - 50 : Satellite Radio (S-Radio)

  - 90 : Cable TV (CADTV)

  - a0 : Cable Radio (CA-Radio)

*  Tune Command Examples:

1. Tune to the Analog antenna (PAL) Channel 10.

Set ID = All = 00

Data 00 & 01 = Channel Data is 10 = 00 0a

Data 02 = Analog Antenna TV = 00

Result =

ma 00 00 0a 00

2. Tune to the digital antenna (DVB-T) Channel 01.

Set ID = All = 00

Data 00 & 01 = Channel Data is 1 = 00 01

Data 02 = Digital Antenna TV = 10

Result =

ma 00 00 01 10

3. Tune to the satellite (DVB-S) Channel 1000.

Set ID = All = 00

Data 00 & 01 = Channel Data is 1000 = 03 E8

Data 02 = Digital Satellite TV = 40

Result =

ma 00 03 E8 40

Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]
[Data 02][x][a][ ][Set ID][ ][NG][Data 00][x]

•

For South Korea, North/Latin America except

Colombia Model

►

To tune channel to following physical/major/minor

number.

Transmission [m][a][ ][0][ ][Data00][ ][Data01]
[ ][Data02][ ][Data03][ ][Data04][ ][Data05][Cr]

Digital channels have a Physical, Major, and Minor

channel number. The Physical number is the actual

digital channel number, the Major is the number that

the channel should be mapped to, and the Minor is

the sub-channel. Since the ATSC tuner automatically

maps the channel from the Major / Minor number,

the Physical number is not required when sending a

command in Digital.
*  Analog Antenna/Cable

Data  00  : Physical Channel Number

  - Antenna (ATV) : 02~45 (Decimal: 2 ~ 69)

  -  Cable (CATV) : 01, 0E~7D (Decimal : 1, 14~125)

[Data 01 ~ 04]: Major/Minor Channel Number

Data  01 & 02: xx (Don't care)

Data  03 & 04: xx (Don't care)

Data  05: Input Source (Analog)

  - 00 : Antenna TV (ATV)

  - 01 : Cable TV (CATV)
*  Digital Antenna/Cable

Data  00 : xx (Don't care)

[Data 01][Data 02]: Major Channel Number

Data  01 : High byte Channel Data

Data  02 : Low byte Channel Data

  - 00 01 ~ 27 0F (Decimal: 1 ~ 9999)

[Data 03][Data 04]: Minor Channel Number

Data  03 : High byte Channel Data

Data  04 : Low byte Channel Data

Data  05 : Input Source (Digital)

  - 02 :  Antenna TV (DTV) – Use Physical Channel

Number

  - 06 :  Cable TV (CADTV) – Use Physical Channel
