4

ENG

ENGLISH

4

EXTERNAL CONTROL DEVICE SETUP

Phone jack Type

•

You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and

the TV, which is specified in the manual.

*  For other models, connect to the USB port.
*  The connection interface may differ from your TV.

USB IN

(TV)

(PC)

(PC)

RS-232C IN

(CONTROL & SERVICE)

(TV)

(TV)

(PC)

(TV)

(PC)

SERVICE ONLY

RS-232C IN

(CONTROL & SERVICE)

RS-232C IN

(CONTROL & SERVICE)

1

3

2

1

3

2

- or

USB IN

(TV)

(PC)

(PC)

RS-232C IN

(CONTROL & SERVICE)

(TV)

(TV)

(PC)

(TV)

(PC)

SERVICE ONLY

RS-232C IN

(CONTROL & SERVICE)

RS-232C IN

(CONTROL & SERVICE)

1

3

2

1

3

2

Customer Computer

RS-232C configurations

3-Wire Configurations(Not standard)

1

6

5

9

PC

TV

RXD

2

2

TXD

TXD

3

1

RXD

GND

5

3

GND

OR

RXD

3

2

TXD

TXD

2

1

RXD

GND

5

3

GND

D-Sub 9

Phone

RS-232C

(Serial port)

Set ID

For Set ID number, see "

Real Data Mapping

" on p.6

1.

Press

SETTINGS

 to access the main menus.

2.

Press the Navigation buttons to scroll to

(*General → About this TV or OPTION)

 and press

OK

.

3.

Press the Navigation buttons to scroll to

SET ID

 and press

OK

.

4.

Scroll left or right to select a set ID number and select

CLOSE

. The adjustment range is 1-99.

5.

When you are finished, press

EXIT

.

* (Depending on model)
