EXTERNAL CONTROL DEVICE SETUP

24. Input select (Command: x b)

(Main Picture Input)

►

To select input source for main picture.

Transmission [x][b][ ][Set ID][ ][Data][Cr]

Data

  00 :  DTV

  02 :  Satellite DTV

ISDB-BS (Japan)

  03 : ISDB-CS1 (Japan)

  04 : ISDB-CS2 (Japan)

  11 : CATV

01 : CADTV

10 : ATV

  20 : AV or AV1

21 : AV2

  40 : Component1

     60 : RGB

41 : Component2

  90 : HDMI1

  92 : HDMI3

91 : HDMI2

93 : HDMI4

Ack [b][ ][Set ID][ ][OK/NG][Data][x]

*  This function depends on model and signal.

25. 3D(Command: x t) (only 3D models)

(Depending on model)

►

To change 3D mode for TV.

Transmission [x][t][ ][Set ID][ ][Data 00][ ][Data 01]
[ ][Data 02][ ][Data 03][Cr]

* (Depending on model)

Data  Structure

[Data 00]   00 : 3D On

01 : 3D Off

02 : 3D to 2D

03 : 2D to 3D

[Data 01]   00 : Top and Bottom

01 : Side by Side

02 : Check Board

03 : Frame Sequential

04 : Column interleaving

05 : Row interleaving

[Data 02]   00 : Right to Left

01 : Left to Right

[Data 03]   3D Effect(3D Depth): Min : 00 - Max : 14

(*transmit by Hexadecimal code)

*  [Data 02], [Data 03] functions depend on model

and signal.

*  If [Data 00] is 00 (3D On), [Data 03] has no

meaning.

*  If [Data 00] is 01 (3D off) or 02 (3D to 2D), [Data

01], [Data 02] and [Data 03] have no meaning.

*  If [Data 00] is 03 (2D to 3D), [Data 01] and

[Data 02] have no meaning.

*  If [Data 00] is 00 (3D On) or 03 (2D to 3D), [Data

03] works when 3D Mode (Genre) is manual only.

*  All 3D pattern options ([Data 01]) may not be

available according to broadcasting/video signal.

[Data 00]

[Data 01]

[Data 02]

[Data 03]

00

O

O

O

01

X

X

X

02

X

X

X

03

X

O

O

X : don’t care

Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02]
[Data03][x]
[t][ ][Set ID][ ][NG][Data00][x]

26. Extended 3D(Command: x v) (only 3D models)

(Depending on model)

►

To change 3D option for TV.

Transmission [x][v][ ][Set ID][ ][Data 00][ ]
[Data 01][Cr]

[Data 00]   3D option

00 : 3D Picture Correction

01 : 3D Depth (3D Mode is Manual Only)

02 : 3D Viewpoint

06 : 3D Color Correction

07 : 3D Sound Zooming

08 : Normal Image View

09 : 3D Mode (Genre)

[Data 01]   It has own range for each 3D option

determined by [Data 00].

1) When  [Data 00] is 00

00 : Right to Left

01 : Left to Right

2) When  [Data 00] is 01, 02

Data     Min: 0 - Max: 14 (*transmit by Hexadecimal

code)

Data value range(0 - 20) converts Viewpoint range

(-10  -  +10) automatically (Depending on model)

*  This option works when 3D Mode (Genre) is manual

only.

3) When  [Data 00] is 06, 07

00 : Off

01 : On

4) When  [Data 00] is 08

00 :  Revert to 3D video from 3D-to-2D

converted 2D video

  01 :  Change 3D video to 2D video, except

2D-to-3D video

*  If conversion condition doesn’t meet, command is

treated as NG.

5) When [Data 00] is 09
00 : Standard

02 : Cinema

04 : Manual

01 : Sport

03 : Extreme

05 : Auto

Ack [v][ ][Set ID][ ][OK][Data00][Data01][x]
[v][ ][Set ID][ ][NG][Data00][x]
