SCC-C6407P
Contents
- Zoom lens single body WDR SmartDome CAMERA
- AC 24 ± 10% (50Hz ± 0.3Hz)
- 22W
- PAL STANDARD COLOR SYSTEM
- 1/4 inch WDR compatible Exview HAD CCD
- 752(H) x 582(V)
- 625 Lines, 2:1 Interlace
- Horizontal : 15, 625Hz(INT) / 15, 625 Hz(L/L)
- Vertical : 50 Hz(INT) / 50 Hz(L/L)
- INT/LINE LOCK
- 480 TV LINES
- 50dB (AGC OFF)
- COLOR : 0.18 Lux (SENS UP X4)
0.005 Lux (SENS UP X160)
- B/W : 0.018 Lux (SENS UP X4)
0.0005 Lux (SENS UP X160)
- 128
- ATW1/ATW2/AWC/MANUAL MODE
(3200K, 5600K, R/B GAIN Court)
- COMPOSITE VIDEO OUT : 1.0 Vp-p 75 ohms/BNC
- one body; 32x Zoom lens
- Focal length : 3.55 to 113 mm
- Aperture : F1.69(Wide), F4.17(Tele)
- MOD(Minimum Object Distance) : 2.5m
- PAN range : 360° Endless
- Preset Pan Speed : 400° /sec, maximum
- Manual Pan Speed : 0.1° ~ 180° /sec (64Step)
- TILT range : 0° ~ 180°
- Preset Tilt Speed : 200° /sec, maximum
- Manual Tilt Speed : 0.1° ~ 90° /sec (64Step)
- Tele/Wide(ZOOM), NEAR/FAR(FOCUS),
Iris Open/Close, Pan/Tilt, MENU
RS-485 HALF/FULL Duplex, RS-422
- Alarm Inputs : 8 IN(5mA Sink)
- Alarm Outputs : 3 OUT (Open collector : 2
DC24V 40mA Max, Relay : 1, NO, NC, COM
2A 30VDC, 0.5A 125VAC Max)
- -10°C ~ +50°C
- ~90%
- DOME : 147 (ø),
- Outline : 159.6(ø) x 177(H)
- 1.7Kg
- Slip-ring
- Fan
Remark
NO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Items
Product Type
Power Input
Power Consumption
Broadcasting Type
Image Device
Effective Pixels
Scanning Mode
Scanning line Frequency
Synchronization Mode
Resolution
S/N Ratio
Min. Object Illumination
WDR
Color Temperature
Signal Output
Lens
PAN Function
TILT Function
REMOTE CONTROL
ALARM
Operation Temperature
Operation Humidity
SIZE
Weight
Lives of Main Parts
Rotated
10,000,000
Times
4.5 Years
Cautions
• The copyright of the manual belongs to Samsung Electronics Co., Ltd.
• Without the permission of Samsung Electronics it cannot be reproduced
electronically, mechanically, audibly, or by any other method.
• This manual will be modified according to product enhancements.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with
separate collection systems)
This marking shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life. To prevent
possible harm to the environment or human health from uncontrolled waste
disposal, please separate this from other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can take
this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of
the purchase contract. This product should not be mixed with other commercial
wastes for disposal.
