The REVERSE function applies PRIVACY MASK to the other area than
set as a privacy zone. ON/OFF is available.
ZONE DIR SET/ZONE AREA SET
This function indicates the ID or direction depending on the set value
when PAN of SCC-C6407(P) is located in a specific area. If set to AREA,
it indicates the ID of the selected area and if set to
N(NORTH), NE(NORTH-
EAST), E(EAST), SE(SOUTH-EAST), S(SOUTH), SW(SOUTH-WEST), W(WEST),
NW(NORTH-WEST
.
EXIT
"QUIT" : Does not save the selected information and returns to a higher
menu.
"SAVE" : Do saves the selected information and returns to a higher menu.
"DEL" : Deletes the selected information and restores the DEFAULT.
Then returns to a higher menu.
PRIVACY ZONE SET 0
SET ZONE AREA ON...
SET ZOOM ...
REVERSE ON
EXIT
QUIT
SET ZOOM
Press [ENTER] at the “SET ZOOM...” position to enter the ZOOM setup
screen. After ZOOM setup, the PRIVACY ZONE function will be in action
only at the higher magnification than the Zoom magnification
as set.
➜
Press
[Enter]
SET ZOOM
PRIVACY ZONE SET 0
SET ZONE AREA ON...
SET ZOOM ...
REVERSE OFF
EXIT
QUIT
➜
After P/T/Z
control, press
[ENTER]
➜
After P/T/Z
control, press
[ENTER]
PRIVACY ZONE P/T 3
PRIVACY ZONE P/T 2
PRIVACY ZONE P/T 4
SET ZONE AREA
Press [ENTER] at the “SET ZONE AREA...” position to enter the
PRIVACY ZONE setup screen. Control PAN/TILT/ZOOM to select 4
apexes of the PRIVACY ZONE area and the rectangular PRIVACY
ZONE area will be completed.
➜
Press
[Enter]
➜
After P/T/Z
control, press
[ENTER]
PRIVACY ZONE P/T 1
PRIVACY ZONE SET 0
SET ZONE AREA ON...
SET ZOOM ...
REVERSE OFF
EXIT
QUIT
❈
For the safer privacy protection, select about 10 % more than the
actual size to hide when you set up the PRIVACY ZONE area.
❈
4 points of PRIVACY ZONE area are in the middle of the screen.
Therefore, when the tilt is positioned at upside limit(0° or 180°),
PRIVACY ZONE cannot be set in the area which is displayed
above center.
❈
If the points becomes X shape, it means PRIVACY ZONE cannot
be set due to the size limitation.
●
●
●
●
