3-5
3-6
E
COLOR/BW
In the COLOR/BW menu, you can switch ON or OFF the IR (infrared) Filter.
In a poor illumination environment, the IR filter is turned off in the BW mode the its
sensitivity increases as high as a black and white camera. On the other hand, the
IR filter is turned on and the sensitivity decreases in the COLOR mode.
COLOR
: The IR Filter is ON and the screen is normal. You can press the
[Enter] key to set the COLOR GAIN LEVEL. And when the AGC
function is on, you can set the AGC COLOER LEVEL.
BW
: The IR Filter is OFF and the screen is black and white.
(Sensitivity to low light is increased to a level comparable to a black
and white camera.)
Select BW and press [ENTER] and the additional menu to select
BURST ON/OFF will appear.
AUTO
: Select to automatically switch between the COLOR mode and BW
mode depending on the amount of light. In low light conditions, the
IR Filter is turned OFF and the sensitivity to low light is increased
by switching to the BW mode, but in bright light conditions, the IR
Filter is turned ON and the sensitivity is decreased by switching to
the COLOR mode.
Select AUTO and press [ENTER] and the additional menu to select
BW LEVEL and DURATION will appear.
- BURST ON
: The color burst signal is output together with black and white
composite video signal.
- BURST OFF
: The color burst signal is not output.
- LEVEL
: You can set the brightness level that changes from COLOR mode
to BW mode in 3 steps : LOW, MEDIUM, and HIGH.
- DURATION
: Set the HOLDING time for switching between COLOR and BW
mode depending the changes in the amount of light. You can set
the HOLDING time to 10sec (S), 30sec, 60sec, or 300sec( L).
➜
Press
[Enter]
(CAMERA SET)
CAMERA ID
OFF
V-SYNC
LINE...
COLOR/BW
COLOR...
MOTION DET
OFF
ZOOM SPEED
3
DIGITAL ZOOM
OFF
DISPLAY ZOOM OFF
DISPLAY P/T OFF
EXIT
QUIT
➜
Press
[Enter]
* " ... " Means there are Sub Menus.
(CAMERA SET)
CAMERA ID
ON...
V-SYNC
INT
COLOR/BW
COLOR...
MOTION DET
OFF
ZOOM SPEED
3
DIGITAL ZOOM
OFF
DISPLAY ZOOM OFF
DISPLAY P/T
OFF
EXIT
QUIT
(CAMERA ID)
A B C D E F G H I J K L
M N O PQ R S T U V W X
Y Z 0 1 2 3 4 5 6 7 8 9
: ! - +
✽
( ) /
S P
ï î
S P
L O C A T I O N . . .
R E T
S C C - C 6 4 0 7 ( P ) P . . . . . . . .
V-SYNC
In the V-SYNC menu, vertical synchronization can be selected. The
vertical synchronization signal supported by the SCC-C6407(P) is the INT
mode made by clock inside the SCC-C6407(P) and LINE mode adjusting
vertical synchronization to the exterior power frequency.
Select LINE and press [Enter]. You will see the LINE LOCK submenu
where you can adjust the phase of the LINE LOCK.
You can use the PHASE menu of the LINE LOCK submenu to assign as
much PHASE as you want.
(LL-PHASE)
PHASE (-106)I--------
RET
➜
Press
[Enter]
(COLOR)
GAIN (0)I--------
AGC COLOR
(0)----I----
RET
(CAMERA SET)
CAMERA ID
OFF
V-SYNC INT
COLOR/BW COLOR
…
MOTION OFF
ZOOM SPEED
3
DIGITAL ZOOM OFF
DISPLAY ZOOM OFF
DISPLAY P/T
OFF
EXIT QUIT
00547A_C6407P-E+R+P
6/5/06
10:41
AM
˘`
3-5
