LOCATION
The “LOCATION...” menu designates the left/right LIMIT positions of
ZONE AREA. Enter the setup screen to move PAN, then select a start
position and press [ENTER]. Move PAN again
to select a end position and press [ENTER]. Now, ZONE AREA setup is
complete.
➜
Press
[Enter]
After PAN control,
press [ENTER] to
finish.
SET START!
ZONE AREA SET 0
LOCATION ...
ZONE ID SET ...
ZONE ENABLE ON
EXIT
QUIT
➜
After P/R/Z
control, press
[ENTER]
SET END!
ZONE AREA SET 0
LOCATION ...
ZONE ID SET ...
ZONE ENABLE ON
EXIT
QUIT
ZONE ID SET
This function is used to allocate as many as 12 IDs to each zone area.
Use Left , Right, UP, or DOWN for this purpose. You may select the ID
position from the additional menu of “LOCATION...”.
ZONE ENABLE
This function turns on or off the ZONE AREA ID indication.
➜
Press
[Enter]
ZONE AREA ID 0
A B C D E F G H I J K L
M N O P Q R S T U V W X
Y Z 0 1 2 3 4 5 6 7 8 9
: ! - +
✽
( ) /
S P
ï î
S P
L O C A T I O N . . .
R E T
Z O N E 0 . . . . . . . .
ZONE DIR SET
Press the [Enter] key in the “ZONE DIR SET ON…” mode to enter the
NORTH SET screen. MAP. Move PAN to set the NORTH position and
press [ENTER]. Based on the North position,the direction of N(North),
NE(North-East), E(East), SE(South-East), S(South), SW(South-West),
W(West), NW(North-West) is displayed whenever you move PAN.
ZONE AREA
Press [ENTER] to enter the ZONE AREA MAP screen from “ZONE
AREA SET...”. Select a ZONE AREA number from the ZONE AREA MAP
screen and press [ENTER] to enter the ZONE AREA setup screen.
➜
Press
[Enter]
(ZONE AREA MAP)
0 *
1 2 3
4 5 6 7
RET
(ZONE SET)
PRIVACY ZONE
...
ZONE DIR SET
OFF
ZONE AREA SET ON...
EXIT
QUIT
➜
Press
[Enter]
(ZONE SET)
PRIVACY ZONE
...
ZONE DIR SET
ON...
ZONE AREA SET OFF
EXIT
QUIT
SET NORTH
N
ZONE AREA SET 0
LOCATION ...
ZONE ID SET ...
ZONE ENABLE ON
EXIT
QUIT
➜
Press
[Enter]
