22

 | English

3 609 929 B90 | (1.10.09)

Bosch Power Tools

f

When working stone, use dust extraction.
The vacuum cleaner must be approved for
the extraction of stone dust.

Using this

equipment reduces dust-related hazards.

f

Use a cutting guide when cutting stone.

Without sideward guidance, the cutting disc
can jam and cause kickback.

f

When working with the machine, always
hold it firmly with both hands and provide
for a secure stance.

The power tool is guided

more secure with both hands.

f

Secure the workpiece.

A workpiece clamped

with clamping devices or in a vice is held
more secure than by hand.

f

Keep your workplace clean.

Blends of mate-

rials are particularly dangerous. Dust from
light alloys can burn or explode.

f

Never use the machine with a damaged ca-
ble. Do not touch the damaged cable and
pull the mains plug when the cable is dam-
aged while working.

Damaged cables in-

crease the risk of an electric shock.

Products sold in GB only

: Your product is fitted

with an BS 1363/A approved electric plug with
internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets,
it should be cut off and an appropriate plug fit-
ted in its place by an authorised customer serv-
ice agent. The replacement plug should have the
same fuse rating as the original plug.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.

Products sold in AUS and NZ only

: Use a resid-

ual current device (RCD) with a rated residual
current of 30 mA or less.

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

The machine is intended for cutting metal and
stone materials without using water while rest-
ing firmly with the cutting guide on the work-
piece.
For cutting stone, a special cutting guide with
dust extraction protection guard (accessory)
must be used.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1

Bow handle

2

Thread for bow handle

3

Spindle lock button

4

Grinder spindle

5

Protection guard for cutting

6

Screw for adjustment of protection guard

7

Clamping lever for protection guard

8

Mounting flange

9

Grinding/cutting disc *

10

Face plate

11

Quick-clamping nut

*

12

Clamping nut

13

Allen Key **

14

Cutting guide

15

On/Off switch

16

Encoding key

17

Cutting guide with dust extraction protec-
tion guard *

18

Elbow  *

19

Handle (insulated gripping surface)

* Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
** Commercially available (not included in the deliv-
ery scope)
