 | English

1 609 92A 0E8 | (22.8.13)

Bosch Power Tools

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



Release the On/Off switch and set it to the off position
when the power supply is interrupted, e. g., in case of a
power failure or when the mains plug is pulled.

This pre-

vents uncontrolled restarting.



Do not touch grinding and cutting discs before they
have cooled down.

The discs can become very hot while

working.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

Products sold in GB only

: Your product is fitted with an

BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for cutting, roughing and brushing of
metal and stone materials without the use of water.
For cutting with bonded abrasives, a special cutting guard
(accessory) must be used.
When cutting in stone, provide for sufficient dust extraction.
With approved sanding tools, the machine can be used for
sanding with sanding discs.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Release lever for protection guard

2

Spindle lock button

3

On/Off switch

4

Auxiliary handle (insulated gripping surface)

5

Grinder spindle

6

Extraction hood for sanding *

7

Mounting flange with O-ring

8

Carbide grinding head *

9

Clamping nut

10

Quick-clamping nut

*

11

Protection guard for grinding

12

Grinding wheel *

13

Protection guard for cutting *

14

Cutting disc *

15

Hand guard *

16

Rubber sanding plate *

17

Sanding sheet *

18

Round nut *

19

Cup brush *

20

Cutting guide with dust extraction protection guard *

21

Diamond cutting disc *

22

Handle (insulated gripping surface)

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:
Sound pressure level 91 dB(A); Sound power level
102 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Surface grinding: a

h

= 8.5 m/s

2

, K = 1.5 m/s

2

,

Disk sanding: a

h

= 3.0 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in EN
60745 and may be used to compare one tool with another. It
may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
