87
Chapter 7
• Service Name
- The service name should not be configured unless you are sure it is
necessary for your ISP. In most cases, leaving these fields blank will work.
• Access Concentrator Name
- The access concentrator name should not be configured
unless you are sure it is necessary for your ISP. In most cases, leaving these fields blank
will work.
• Detect Online Interval
- The router will detect Access Concentrator online at every
interval. The default value is 10. You can input the value between 0 and 120. The value 0
means no detect.
• IP Address
- The default setting is to get an IP address dynamically from your ISP. If your
ISP does not automatically assign IP addresses to the router, please select
Use the
Following IP Address
and enter the IP address provided by your ISP in dotted-decimal
notation.
• DNS Address
- The default setting is to get an IP address dynamically from your ISP. If
your ISP does not automatically assign DNS addresses to the router, please select
Use
the Following DNS Addresses
and enter the IP address in dotted-decimal notation of
your ISP’s primary DNS server. If a secondary DNS server address is available, enter it as
well.
• Connection Mode
- Select an appropriate connection mode that determines how to
connect to the internet.
• Auto
- In this mode, the internet connection reconnects automatically any it gets
disconnected.
• On Demand
- In this mode, the internet connection will be terminated automatically
after a specified inactivity period (Max Idle Time) and be re-established when you
attempt to access the internet again.
• Time-based
- In this mode, the internet connection is only established in a specific
timeframe. If this option is selected, enter the start time and end time. Both are in
HH:MM format.
• Manual
- In this mode, the internet connection is controlled manually by clicking the
Connect/Disconnect
button. This mode also supports the
Max Idle Time
function
as
On Demand
mode. Enter a maximum time (in minutes), the internet connection
can be inactive before it is terminated into the Max Idle Time. The default value is
15 minutes. If you want the internet connection remains active all the time, enter 0
(zero).
Note:
Sometimes the connection cannot be terminated although you have specified the
Max Idle Time
because some applications
are visiting the internet continually in the background.
L2TP
If your ISP provides L2TP connection, please select
L2TP
.
