21

Chapter 4

•  VPN Server IP/ Domain Name

- Enter the VPN server’s IP address or domain name

provided by your ISP.

•  MTU Size

 - The default MTU size is “1420” bytes, which is usually fine. It is not

recommended that you change the default MTU Size unless required by your ISP.

•  Connection Mode

•  Auto

 - In this mode, the internet connection reconnects automatically any it gets

disconnected.

•  On Demand

 - In this mode, the internet connection will be terminated automatically

after a specified inactivity period (Max Idle Time) and be re-established when you
attempt to access the internet again.

•  Manual

 - In this mode, the internet connection is controlled manually by clicking the

Connect/Disconnect

 button. This mode also supports the

Max Idle Time

 function

as

On Demand

 mode. Enter a maximum time (in minutes), the internet connection

can be inactive before it is terminated into the Max Idle Time. The default value is
15 minutes. If you want the internet connection remains active all the time, enter 0
(zero).

Note:

Sometimes the connection cannot be terminated although you have specified the

Max Idle Time

 because some applications

are visiting the internet continually in the background.

4. 2. 3.  MAC Clone

1. Visit

http://mwlogin.net

, and log in with the password you set for the router.

2. Go to

Advanced

>

Network

 >

Internet

 and locate the MAC Clone section.

3.

Configure

Router MAC Address

 and click

SAVE

.

•  Use Default MAC Address

 - Do not change the default MAC address of your router

in case the ISP does not bind the assigned IP address to the MAC address.

•  Use Current MAC Address

- Select to copy the current MAC address of the

computer that is connected to the router, in case the ISP binds the assigned IP
address to the MAC address.
