96

Chapter 7

sends out data. In the example, the data packets will be sent to the LAN port of
Router B and then to the Server, so the default gateway should be 192.168.1.2.

•  Interface

- Determined by the port (WAN/LAN) that sends out data packets. In the

example, the data are sent to the gateway through the LAN port of Router A, so

LAN

should be selected.

•  Description

-  Enter a description for this static routing entry.

5.

Click

SAVE

.

6.

Check the

Routing Table

 below. If you can find the entry you’ve set, the static routing is

set successfully.

7. 3.  Wireless

7. 3. 1.  Wireless Settings

1. Visit

http://mwlogin.net

, and log in with the password you set for the router.

2. Go to

Advanced

>

Wireless

>

Wireless Settings

.

3.

Configure the wireless settings for the wireless network and click

SAVE

.

•  2.4GHz

 - Select this checkbox to enable the 2.4GHz wireless network.

•  Network Name (SSID)

 - Enter a value of up to 32 characters. The same Name (SSID) must

be assigned to all wireless devices in your network.

•  Hide SSID

- Select this checkbox if you want to hide the 2.4GHz network name (SSID)

from the Wi-Fi network list. In this case, you need to manually join the network.

•  Security

 - Select an option from the Security drop-down list.

•  None

- No security. It is highly recommend you enable the wireless security to

protect your wireless network from unauthorized access.
