36

Chapter 4

•

You can add multiple virtual server rules if you want to provide several services in a router. Please note that

the

 External Port

should not be overlapped.

Done!

Users on the internet can enter

http:// WAN IP

 (in this example: http:// 218.18.232.154) to

visit your personal website.

Note:

•

If you have changed the default

External Port

, you should use

http:// WAN IP: External Port

 to visit the

website.

•

The WAN IP should be a public IP address. For the WAN IP is assigned dynamically by the ISP, it is

recommended to apply and register a domain name for the WAN referring to

Dynamic DNS

. Then users on

the internet can use

http:// domain name

 to visit the website.

4. 4. 2.  Port Triggering

Port triggering can specify a triggering port and its corresponding external ports. When a
host in the local network initiates a connection to the triggering port, all the external ports
will be opened for subsequent connections. The router can record the IP address of the
host. When the data from the internet return to the external ports, the router can forward
them to the corresponding host. Port triggering is mainly applied to online games, VoIPs,
video players and common applications including MSN Gaming Zone, Dialpad, Quick Time 4
players and more.
Follow the steps below to configure the port triggering rules:

1. Visit

http://mwlogin.net

, and log in with the password you set for the router.

2. Go to

Advanced

 >

NAT Forwarding

 >

Port Triggering

.

3.

Click

Add

.

4. Click

VIEW COMMON SERVICES

, and select the desired application. The Triggering Port,

Triggering Protocol and External Port will be automatically filled in. The following picture
takes application MSN Gaming Zone as an example.
