Dyson V8 Absolute + - Инструкция по эксплуатации - Страница 38

38

EN

USING YOUR DYSON APPLIANCE

PLEASE READ THE ‘IMPORTANT SAFET Y INSTRUCTIONS’ IN THIS DYSON

OPER ATING M ANUAL BEFORE PROCEEDING.

DOCKING STATION INSTALLATION

•

Use appropriate mounting hardware for your wall type and ensure that the docking

station is mounted securely. Ensure no pipe work (gas, water, air) or electrical

cables, wires or ductwork are located directly behind the mounting area. The

docking station must be mounted in accordance with regulations and applicable

codes/standards (state and local laws may apply). Dyson recommends the use of

protective clothing, eyeware and materials when installing the docking station.

OPER ATION

•

Do not use outdoors or on wet surfaces or to vacuum water or other liquids – electric

shock could occur.

•

Ensure the appliance remains upright in use and in storage. Dirt and debris may be

released if it is turned upside down.

•

Do not operate while checking for blockages.

•

For domestic indoor and car use only. Do not use it whilst the car is in motion or

while driving.

•

To operate the Max mode, locate the switch on the top of the appliance. Slide the

switch to the Max mode position.

•

To switch off Max mode, slide the switch back to the Powerful Suction

mode position.

•

This product has carbon fibre brushes. Take care if coming into contact with

them, as they may cause minor skin irritation. Wash your hands after handling

the brushes.

VACUUMING

•

Do not use without the clear bin and filters in place.

•

Fine dirt such as flour should only be vacuumed in very small amounts.

•

Do not use the appliance to pick up sharp hard objects, small toys, pins, paper

clips, etc. They may damage the appliance.

•

When vacuuming, certain carpets may generate small static charges in the clear

bin or wand. These are harmless and are not associated with the mains electricity

supply. To minimise any effect from this, do not put your hand or insert any object

into the clear bin unless you have first emptied it. Clean the clear bin with a damp

cloth only. (See ‘Cleaning the clear bin’.)

•

Use extra care when cleaning on stairs.

•

Do not rest the appliance on chairs, tables, etc.

•

Do not press down on the nozzle with excessive force when using the appliance as

this may cause damage.

•

Do not leave the cleaner head in one place on delicate floors.

•

On waxed floors the movement of the cleaner head may create an uneven lustre.

If this happens, wipe with a damp cloth, polish the area with wax, and wait for it

to dry.

CARPETS OR HARD FLOORS

•

Before vacuuming your flooring, rugs and carpets, check the manufacturer’s

recommended cleaning instructions.

•

The brush bar on the appliance can damage certain carpet types and floors. Some

carpets will fuzz if a rotating brush bar is used when vacuuming. If this happens, we

recommend vacuuming without the motorised floor tool and consulting with your

flooring manufacturer.

•

Before vacuuming highly polished floors, such as wood or lino, first check that the

underside of the floor tool and its brushes are free from foreign objects that could

cause marking.

DIAGNOSTICS – LIGHTS DURING CHARGING

DIAGNOSTICS – DURING USE

EMPTYING THE CLEAR BIN

•

Empty as soon as the dirt reaches the level of the M A X mark – do not overfill.

•

Ensure that the appliance is disconnected from the charger before emptying the

clear bin. Be careful not to pull the 'ON' trigger.

•

To make emptying the clear bin easier, it is advisable to remove the wand and

floor tool.

•

To minimise dust/allergen contact when emptying, encase the clear bin tightly in a

plastic bag and empty.

•

To release the dirt, hold the appliance by the handle, pull the red lever back and lift

upwards to release the cyclone. Continue until the bin base automatically opens

and releases the dirt.

•

Remove the clear bin carefully from the bag.

•

Seal the bag tightly, dispose as normal.

•

To close, push the cyclone downwards until it is in the normal position and manually

close the base of the bin – the base will click when it is securely in place.

CLEANING THE CLEAR BIN

•

Ensure the appliance is disconnected from the charger before removing the clear

bin. Be careful not to pull the ‘ON’ trigger.

•

Remove the wand and floor tool.

•

To remove the cyclone, hold the appliance by the handle, pull the red lever towards

you and lift upwards until the bin opens, then push in the red button located behind

the cyclone and lift the cyclone out.

•

To detach the clear bin from the appliance, pull back on the red catch located at the

base, slide the clear bin down and carefully remove forwards from the main body.

•

Clean the clear bin with a damp cloth only.

•

Do not use detergents, polishes or air fresheners to clean the clear bin.

•

Do not put the clear bin in a dishwasher.

•

Ensure the clear bin is completely dry before replacing.

•

To replace the clear bin, align the tabs on the clear bin with the grooves on the main

body and slide upwards into place until the catch clicks.

•

Slide the cyclone into the grooves of the main body and push downwards until it is in

its normal position and manually close the base of the bin – the base will click when

it is securely in place.

WASHABLE PARTS

Your appliance has washable parts, which require regular cleaning. Follow the

instructions below.

WASHING THE BRUSH BAR

•

Your appliance has a washable brush bar, check and wash it regularly according to

the following instructions to maintain performance.

•

Ensure the appliance is disconnected from the charger before removing the brush

bar. Be careful not to pull the ‘ON’ trigger.
TO REMOVE, WASH AND REPL ACE THE BRUSH BAR:

•

Please refer to the ' Washing the brush bar' illustrations alongside the

instructions below.

•

Turn the cleaner head upside down so the underside of the cleaner head is

facing you. Use a coin to turn the fastener one quarter anti-clockwise to the

unlocked position.

•

Rotate the end cap to the open position. Gently slide the brush bar away from the

cleaner head.

•

Remove the end cap from the brush bar.

•

Hold the brush bar under running water and gently rub to remove any lint or dirt.

•

Stand the brush bar upright as shown. Leave to dry completely for a minimum of

24 hours.

•

Before replacing, check that the brush bar is completely dry.

•

Reattach the end cap to the brush bar.

•

Slide the brush bar back onto the cleaner head, around the motor. The end cap

should be in the open position as shown. Once in place, rotate the end cap back

into the closed position.

•

Close the fastener by turning a quarter turn clockwise. Ensure that the fastener is

fully turned and the brush bar is secure.

Charging, low charge.

Charging, nearly full.

Charger fault – call the

Dyson Helpline.

Charging, medium charge.

Fully charged.

Battery fault – call the

Dyson Helpline.

High level of charge.

Low level of charge.

Battery fault – call the

Dyson Helpline.

Medium level of charge.

Empty, needs recharging.

Main body fault – call the

Dyson Helpine.
