36

En

Setup Menu

This function is only available for NTSC video
format and composite video / S-video output.

Switching YUV/RGB
(Europe and Russia models only)

This setting allows you to toggle the output of
the video signal between YUV (on VIDEO
OUT - COMPONENT) and RGB (on
SCART).

•

Select [COMPONENT] in “VIDEO
SETUP PAGE”.

YUV

Select this for the component video
connection.

RGB

Select this for SCART connection.

Setting the HDMI video

When you connect this unit to an HDMI
compatible component via the HDMI jack,
select the following video output settings
depending on the connected component.

1

In “VIDEO SETUP PAGE”, press

5

/

a

 to

highlight [HDMI SETUP], and then press

3

.

2

Press

5

/

a

 to highlight an option.

3

Press

3

 to enter a submenu.

WIDE SCREEN FORMAT

Set the aspect ratio of the projected images on
the screen. This feature is only available when
making HDMI connections and [TV
DISPLAY] is set to [16:9] (see page 33) when
playing back 4:3 image.

SUPERWIDE

Select to display a 4:3 image on the 16:9 screen
with non-linear stretching (center position of
screen is stretched less than the sides).

4:3 PILLAR BOX

Select to display a 4:3 image on the 16:9 screen
without stretching. When playing a disc
recorded in the 16:9 image, the image is
displayed in its original aspect ratio (16:9)
without pillar boxes.

OFF

No aspect ratio adjustment is made when this
option is selected.

When the video signal is 480p or 576p, you cannot
select [WIDE SCREEN FORMAT], and no aspect
ratio adjustment is made even if [SUPERWIDE] or
[4:3 PILLAR BOX] is selected.

HDMI VIDEO

Set the resolution depending on the monitor
you are using. This unit is compatible with the
following video formats:
480p/60Hz, 576p/50Hz, 720p/50Hz, 60Hz,
1080i/50Hz, 60Hz, and 1080p/50Hz, 60Hz

480P

480 progressive-scan video

576P

576 progressive-scan video

720P

720 progressive-scan video

1080I

1080 interlaced video

1080P

1080 progressive-scan video

AUTO

The resolution is automatically selected to
match the monitor you are using.

Note

Note
