C. Configuring a RAID array in RAID BIOS

Enter the RAID BIOS setup utility to configure a RAID array. Skip this step and proceed to the installation
of Windows operating system for a non-RAID configuration.

After the POST memory test begins and before the operating system boot begins, look for a message
which says "Press <Ctrl-G> to enter RAID Setup Utility" (Figure 2). Press <Ctrl> + <G> to enter the
GIGABYTE SATA2 RAID BIOS utility.

Figure 2

Figure 3

GIGABYTE Technology Corp. PCIE-to-SATAII/IDE RAID Controller BIOS v1.06.78
Copyright (C) 2005 GIGABYTE Technology.

http://www.gigabyte.com.tw

HDD0

:

ST3120026AS

120 GB

Non-RAID

HDD1

:

ST3120026AS

120 GB

Non-RAID

ODD0

:

DVDROM GO-D1600B

Press <Ctrl-G> to enter RAID Setup Utility ...

In the main screen of the GIGABYTE SATA2 RAID BIOS utility (Figure 3), use the up or down arrow key
to highlight through choices in the

Main Menu

 block. Highlight the item that you wish to execute and

press <Enter>.

GIGABYTE Technology Corp. PCIE-to-SATAII/IDE RAID Controller BIOS v1.06.78

[ Main Menu ]

Create RAID Disk Drive

Delete RAID Disk Drive
Revert HDD to Non-RAID
Solve Mirror Conflict
Rebuild Mirror Drive
Save And Exit Setup
Exit Without Saving

[ RAID Disk Drive List ]

[



TAB]-Switch Window

[



]-Select ITEM

[ENTER]-Action

   [ESC]-Exit

[ Hard Disk Drive List ]

M odel Name

C a p a c i t y

Type/Status

HDD0: ST3120026AS

120 GB

Non-RAID

HDD1: ST3120026AS

120 GB

Non-RAID

Note:

 In the main screen, you can select a hard drive in the

Hard Disk Drive List

 block and press

<Enter> to see detailed information about the selected hard drive.
