- 51 -
BIOS Setup
2-6
Integrated Peripherals
SATA RAID/AHCI Mode (Intel ICH10R Southbridge)
Enables or disables RAID for the SATA controllers integrated in the Intel ICH10R Southbridge or
configures the SATA controllers to AHCI mode.
Disabled
Disables RAID for the SATA controllers and configures the SATA controllers to
PATA mode. (Default)
RAID
Enables RAID for the SATA controllers.
AHCI
Configures the SATA controllers to AHCI mode. Advanced Host Controller
Interface (AHCI) is an interface specification that allows the storage driver to
enable advanced Serial ATA features such as Native Command Queuing and
hot plug.
SATA Port0-3 Native Mode
Specifies the operating mode of the integrated SATA controllers.
Disabled
Allows the SATA controllers to operate in Legacy IDE mode.
In Legacy mode the SATA controllers use dedicated IRQs that cannot be shared
with other device. Set this option to
Disabled
if you wish to install operating
systems that do not support Native mode. (Default)
Enabled
Allows the SATA controllers to operate in Native IDE mode.
Enable Native IDE mode if you wish to install operating systems that support
Native mode.
USB 1.0 Controller
Enables or disables the integrated USB 1.0 controller. (Default: Enabled)
Disabled
will turn off all of the USB functionalities below.
USB 2.0 Controller
Enables or disables the integrated USB 2.0 controller. (Default: Enabled)
USB Keyboard Function
Allows USB keyboard to be used in MS-DOS. (Default: Disabled)
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Integrated Peripherals
SATA RAID/AHCI Mode
[Disabled]
SATA Port0-3 Native Mode
[Disabled]
USB 1.0 Controller
[Enabled]
USB 2.0 Controller
[Enabled]
USB Keyboard Function
[Disabled]
USB Mouse Function
[Disabled]
USB Storage Function
[Enabled]
Azalia Codec
[Auto]
Onboard H/W 1394
[Enabled]
Onboard H/W LAN1
[Enabled]
Onboard H/W LAN2
[Enabled]
Green LAN
[Disabled]
SMART LAN1
[Press Enter]
SMART LAN2
[Press Enter]
Onboard LAN1 Boot ROM
[Disabled]
Onboard LAN2 Boot ROM
[Disabled]
Onboard SATA/IDE Device
[Enabled]
Onboard SATA/IDE Ctrl Mode
[IDE]
Smart Backup
[Press Enter]
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Integrated Peripherals
SATA RAID/AHCI Mode
[Disabled]
SATA Port0-3 Native Mode
[Disabled]
USB 1.0 Controller
[Enabled]
USB 2.0 Controller
[Enabled]
USB Keyboard Function
[Disabled]
USB Mouse Function
[Disabled]
USB Storage Function
[Enabled]
Azalia Codec
[Auto]
Onboard H/W 1394
[Enabled]
Onboard H/W LAN
[Enabled]
Green LAN
[Disabled]
SMART LAN
[Press Enter]
Onboard LAN Boot ROM
[Disabled]
Onboard SATA/IDE Device
[Enabled]
Onboard SATA/IDE Ctrl Mode
[IDE]
Onboard Serial Port 1
[3F8/IRQ4]
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
