BIOS Setup
2-3
MB Intelligent Tweaker(M.I.T.)
(Note 1) This item appears only if you install a CPU that supports this feature.
(Note 2) This item appears only if you install a memory module that supports this feature.
Whether the system will work stably with the overclock/overvoltage settings you made is
dependent on your overall system configurations. Incorrectly doing overclock/overvoltage
may result in damage to CPU, chipset, or memory and reduce the useful life of these
components. This page is for advanced users only and we recommend you not to alter the
default settings to prevent system instability or other unexpected results. (Inadequately alter-
ing the settings may result in system's failure to boot. If this occurs, clear the CMOS values
and reset the board to default values.)
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
MB Intelligent Tweaker(M.I.T.)
CPU Clock Ratio
(Note 1)
[22X]
CPU Frequency
2.93GHz(133x22)
Advanced CPU Features
[Press Enter]
QPI Link Speed
[Auto]
QPI Link Speed
4.8GHz
UnCore & QPI Features
[Press Enter]
Base Clock(BCLK) Control
[Disabled]
x
BCLK Frequency (Mhz)
133
Advanced Clock Control
[Press Enter]
Performance Enhance
[Turbo]
Extreme Memory Profile (X.M.P.)
(Note 2)
[Disabled]
System Memory Multiplier
(SPD)
[Auto]
Memory Frequency (Mhz)
800
800
DRAM Timing Selectable
(SPD)
[Auto]
Profile DDR Voltage
1.5V
Profile QPI Voltage
1.15V
>>>>> Channel A
x
CAS Latency Time
6
Auto
x
tRCD
6
Auto
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
MB Intelligent Tweaker(M.I.T.)
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
x tRP
6
Auto
x tRAS
16
Auto
>>>>> Channel B
x CAS Latency Time
N/A
Auto
x tRCD
N/A
Auto
x tRP
N/A
Auto
x tRAS
N/A
Auto
>>>>> Channel C
x CAS Latency Time
N/A
Auto
x tRCD
N/A
Auto
x tRP
N/A
Auto
x tRAS
N/A
Auto
Advanced DRAM Features
[Press Enter]
Voltage Types
N o r m a l
Current
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Load-Line Calibration
[Disabled]
CPU Vcore
1.22500V [Auto]
QPI/Vtt Voltage
1.150V
[Auto]
IOH Core
1.100V
[Auto]
DRAM Voltage
1.500V
[Auto]
Advanced Voltage Control
[Press Enter]
Item Help
Menu Level
