GA-EX58-UD3R Motherboard

- 10 -

1-2

Product Specifications

C P U



Support for an Intel

®

 Core

TM

i7 series processor in the LGA 1366 package

(Go to GIGABYTE's website for the latest CPU support list.)



L3 cache varies with CPU

QPI



4.8GT/s, 6.4GT/s

Chipset



North Bridge: Intel

®

 X58 Express Chipset



South Bridge: Intel

®

 ICH10R

M e m o r y



4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory

 (Note 1)



Dual/3 channel memory architecture



Support for DDR3 2000/1333/1066/800 MHz

memory modules

(Go to GIGABYTE's website for the latest memory support list.)

Audio



Realtek ALC888 codec



High Definition Audio



2/4/5.1/7.1-channel



Support for S/PDIF In/Out



Support for CD In

LAN



1 x Realtek 8111D chip (10/100/1000 Mbit)

Expansion Slots



2 x PCI Express x16 slots, running at x16
(The PCI Express slots support ATI CrossFireX

T M

 technology and conform

to PCI Express 2.0 standard.)



1 x PCI Express x4 slot



2 x PCI Express x1 slots



2 x PCI slots

Storage Interface



South Bridge:
-

6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices

-

Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10



GIGABYTE SATA2 chip:
-

1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices

-

2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2
SATA 3Gb/s devices

-

Support for SATA RAID 0, RAID 1 and JBOD



iTE IT8720 chip:
-

1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB



Integrated in the South Bridge



Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)

IEEE 1394



T.I. TSB43AB23 chip



Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a
bracket connected to the internal IEEE 1394a header)
