4 |

Chapter 1: Introduction

1�3

Specifications

Specifications

CPU Support

Support for 12th Generation Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Pentium® processors/
Intel® Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.

Chipset

Intel® B660

Memory

Supports Dual Channel DDR4-1866/ 2133/ 2400/ 2666/2800/2933/3200/3600(OC)/3800(OC)/4000(OC)/
4133(OC)/4300(OC)/5000+(OC)

4x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Each DIMM supports non-ECC 4/ 8/ 16/ 32GB DDR4 module

Support Intel® Extreme Memory Profile (XMP) memory modules

* Please refer to www.biostar.com.tw for Memory support list.

Storage

-- Total supports 3 x M.2 socket and 8 x SATA III (6Gb/s) ports
8x SATA III Connector (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
(Only SATA1

~

SATA4)

1x M.2 (M Key) Socket (M2-PCIE4_64G_1)

Supports M.2 Type 2280 SSD module

Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD
1x M.2 (M Key) Socket (M2_PCIE4_64G_2):

Supports M.2 Type 2280 SSD module

Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD

Supports Intel® Rapid Storage Technology and Intel® Optane Technology

1x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA_1):

Supports M.2 Type 2242/ 2260/ 2280/ 22110 SSD module

Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA lll (6Gb/s)SSD

Supports Intel® Rapid Storage Technology and Intel® Optane Technology

* When using SATA SSD module on M.2 slot(M2_PCIEG3_32G_SATA_1), the SATA_8 connector will be

disabled.

* When using PCIE SSD module on M.2 slot(M2_PCIEG4_64G_2), the PCIEG4X4 slot will be disabled.

LAN

Realtek RTL8125B
10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability

Audio Codec

ALC1220
7.1 Channels, High Definition Audio, Hi-Fi(Front)

USB

2x USB 3.2 (Gen2) Type-C port (1 on rear I/O and 1 via internal header)
5x USB 3.2 (Gen2) port (5 on rear I/Os)
2x USB 3.2 (Gen1) port (2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)

Expansion Slots

2x PCIe 3.0 x1 Slot

1x PCIe 5.0 x16 Slot (x16 mode)
1x PCIe 4.0 x16 Slot (x4 mode)

Rear I/Os

2x WIFI Antenna Port

1x PS/2 Keyboard/ Mouse Port
1x HDMI Port (HDMI2.0)

1x DP Port

1x DVI-D Port
1x USB 3.2 (Gen2) Type-C Port
5x USB 3.2 (Gen2) Port
2x USB 2.0 port
1x LAN port

3x Audio Jack

»

Continued on Next Page
