9

English

B450 Steel Legend

•

1 x Ultra M.2 Socket (M2_1), supports M Key type
2230/2242/2260/2280 M.2 PCI Express module up to Gen3 x4
(32 Gb/s) (with Matisse, Picasso, Summit Ridge, Raven Ridge
and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with Athlon series
APU)**

•

1 x M.2 Socket (M2_2), supports M Key type
2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and
M.2 PCI Express module up to Gen3 x2 (16 Gb/s) **

** If M2_1 is occupied, PCIE4 will be disabled.
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit

Connector

•

1 x COM Port Header

•

1 x TPM Header

•

1 x Power LED and Speaker Header

•

1 x RGB LED Header

* Supports in total up to 12V/3A, 36W LED Strip

•

1 x Addressable LED Header

* Supports in total up to 5V/3A, 15W LED Strip

•

1 x AMD Fan LED Header

* The AMD Fan LED Header supports LED strips of maximum
load of 3A (36W) and length up to 2.5M.

•

1 x CPU Fan Connector (4-pin)

* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.

•

1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)

* The CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.

•

3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)

* The Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and
CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.

•

1 x 24 pin ATX Power Connector

•

1 x 8 pin 12V Power Connector

•

1 x Front Panel Audio Connector

•

2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD
Protection)

•

1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
(Supports ESD Protection)
